Forming Force Analysis in Fine-Blanking Process by Experimental Approach and Analytical Formulation

Abstract:

Large deformation is a major deformation operation in many metal-forming processes, such as forging, rolling, extrusion, stamping and fine-blanking. It is difficult to study the deformation changes in these processes in a practical way, through the measurement of forces, due to the severe and localized nature of plastic deformation such as in the fine-blanking operation. Therefore, the forces analysis of most metal-forming processes cannot be carried out successfully by experiments. Thus, this paper aims to present the development of an effective process of forces measurement in fine-blanking process. Also, the effect of blank geometry and material properties on forming force in fine-blanking process was studied by theoretical formulation and experimental approach. Tensile strength and initial blank thickness were considered in this research. The obtained results indicated that by increasing the initial blank thickness and the tensile strength, the forces in fine-blanking process is increased.

• Periodical: Applied Mechanics and Materials (Volumes 110-116)
• Pages: 2723-2729
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.110-116.2723
• Online since: October 2011
• Authors: Vahid Daiezadeh, Majid Elyasi, Meghdad Mollaei
• Keywords: Fine-Blanking Force, Initial Blank Thickness, Material Tensile Strength

References

[1] Z.H. Chen, C.Y. Tang, T.C. Lee, An investigation of tearing failure in fine-blanking process using coupled thermo-mechanical method, Journal of Materials Processing Technology, International Journal of Machine Tools & Manufacture, vol. 44, 2004, p.155.

DOI: 10.1016/j.ijmachtools.2003.10.010

[2] S. Thipprakmas, Finite element analysis of V-ring indenter mechanism in fine-blanking process, Materials and Design, vol. 30, 2009, pp.526-531.

DOI: 10.1016/j.matdes.2008.05.072

[3] S. Thipprakmas, Application of Taguchi technique to investigation of geometry and position of V-ring indenter in fine-blanking process, Materials and Design, vol. 31, 2010, pp.2496-2500.

DOI: 10.1016/j.matdes.2009.11.046

[4] T.S. Kwak, Y.J. Kim and W.B. Bea, Finite element analysis on the effect of die clearance on shear planes in fine blanking, Journal of Materials Processing Technology, vol. 130-131, 2002, pp.462-468.

DOI: 10.1016/s0924-0136(02)00767-7

[5] W.F. Fan and J.H. Li, An investigation on the damage of AISI-1045 and AISI-1025 steels in fine-blanking with negative clearance, Materials Science and Engineering A, vol. 499, 2009, pp.248-251.

DOI: 10.1016/j.msea.2007.11.108

[6] K. Lange, F. Birzer and H. Singer, Cold forming and fineblanking, ISBN 3-444-10510-X, , 1st ed., vol. 1, 1997, p.160–165.
