The Effects of Flexible Deformation on an Oscillating Airfoil at Low Reynolds Number

Abstract:

The objective of investigation is to use numerical simulation obtain the effect of three different flexible deformation parameters (the maximum deforming amplitude, the phase difference between the plunging motion and the deformation motion and location of the maximum deforming) on unsteady aerodynamic performance of an airfoil with plunging and pitching motion. It is shown the effect of flexible deformation at low Reynolds number is obvious. The effect of the maximum deforming amplitude and the phase difference on aerodynamic forces is quite significant while the time courses of C_L and C_T don’t almost change with location of the maximum deforming. Different deforming amplitude and the phase difference may be advantageous or disadvantageous for averaged aerodynamic forces. Larger phase difference can produce more thrust and make the forward flight faster. Compared with the rigid airfoil, the appreciate combination of deformation parameters is beneficial in MAV design.

• Periodical: Applied Mechanics and Materials (Volumes 117-119)
• Pages: 610-614
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.117-119.610
• Online since: October 2011
• Authors: Jiang Hao Wu, Chao Zhou, Yan Lai Zhang
• Keywords: Aerodynamic Force, Flexibility Deformation, Numerical Simulation, Oscillating Airfoil

References

[1] DC Li, SJ Guo, ND Matteo and DQ Yang, "Design, Experiment and Aerodynamic Calculation of a Flapping Wing Rotor Micro Aerial Vehicle," 52nd AIAA/ASME/ASCE/AHS/ASC Structures, Structural Dynamics and Materials, Denver, Colorado, USA, (2011)

DOI: 10.2514/6.2011-1988

[2] P Wu and P Ifju, AIAA JOURNAL, Vol. 48, No. 9, 2010, pp.2111-2122

[3] L Zhao, QF Huang, XY Deng and S Sane, "The effect of chord-wise flexibility on the aerodynamic forcegeneration of flapping wings: experimental studies," 2009 IEEE International Conference on Robotics and Automation Kobe International Conference Center, Kobe, Japan, 2009, pp.4207-4212

DOI: 10.1109/robot.2009.5152734

[4] W Shyy, Y Lian, J Tang, H Liu, P Trizila, B Stanford, L Bernal, C Cesnik, P Friedmann and P Ifju, "Computational Aerodynamics of Low Reynolds Number Plunging, Pitching and Flexible Wings for MAV Applications," 46th AIAA Aerospace Sciences Meeting and Exhibit,7 - 10 January 2008, AIAA 2008-523

DOI: 10.2514/6.2008-523

[5] L Bao and BG Tong, Journal of the Graduate School of the Chinese Academy of Sciences, 2005, 22(6): 676~ 684 (in Chinese).

[6] JH Wu, D Wang, SJ Guo, "Unsteady Aerodynamics Simulation of A Flapping Wing at Low Reynolds Number", 15th International Forum on Aeroelasticity and Structural Dynamics, Paris, French, 2011.

[7] H Wang, LJ Zeng and CY Yin, Meas. Sci. Tech. 13, 903-908 (2002).

[8] C Heathcote, S Martin and D Gursul, AIAA JOURNAL, Vol. 42,No. 11, November 2004, pp.2196-2204.
