Experimental Investigation on the Heat Transfer Properties of Micro-Channel Flat Plate Heat Pipe

Abstract:

The surface temperature and equivalent heat conductivity of Flat Plate Heat Pipe (FPHP) under different heat flux, liquid filling and tilt angles are investigated experimentally. Electrical discharge machining (EDM) micro-channels wick are select as the wick inside FPHP. A set of experimental facility to measure the temperatures of FPHP is build up. The surface temperature along channels under different tilt angles, liquid filling and heat flux are measured by thermal couples. The results indicate that the temperatures are independent to the tilt angles and liquid filling. The equivalent thermal conductivity increases with the increasing of heat flux, and is 1.36 to 1.44 times to that of brass.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 142-146
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.142
• Online since: October 2011
• Authors: Dong Yao Liu, Xian Hu Ding
• Keywords: Flat Heat Pipe, Heat Transfer, Micro-Channel

References

[1] N. Popova. Fabrication and experimental investigation of innovative sintered very thin copper heat pipes for electronics applications. 2006 IEEE Power Electronics Specialists Conference, No. 06CH37819C.

DOI: 10.1109/pesc.2006.1712210

[2] L.L. Vasiliev. Micro and miniature heat pipes-Electronic component coolers. Applied Thermal Engineering, 2008, 28: 266~273.

DOI: 10.1016/j.applthermaleng.2006.02.023

[3] S. Lips, F. Lefèvre and J. Bonjour. Nucleate boiling in a flat grooved heat pipe. International Journal of Thermal Sciences, 2009, 48(7): 1273~1278.

DOI: 10.1016/j.ijthermalsci.2008.11.011

[4] S-H. Jurgen, J. B. Dezord and C. Schaeffer, etc. DBC (Direct Bond Copper) Substrate with Integrated Flat Heat Pipe. Annual IEEE Semiconductor Thermal Measurement and Management Symposium, 2006: 152~156.

DOI: 10.1109/stherm.2006.1625221
