Weld Quality Improvement with Hybrid FSW Technology Assisted by Preheating for Copper T2/Aluminium 5A06 Dissimilar Materials

Abstract:

Copper and aluminium alloy could be welded by friction stir welding (FSW) but it is quite difficult to achieve a defect-free welding joint for welding dissimilar materials because of the enormous difference of their thermo-physical performances. In this paper, another friction stir tool was applied as a heating source to preheat the copper side to 150~200°C in the welding direction. Preheating temperature can make up the lost heat, improve the temperature of copper plate before the FSW process, achieve the refining grains, and then obtain a high quality welding joint. We concentrated on hybrid heat-source equipments design and procedure optimization in our studies. The microstructure, mechanical properties and phase constituents of FSW joints were studied through mechanical test and metallographic analysis. The results indicated that the hybrid FSW technology with preheating for copper T2/aluminium 5A06 dissimilar materials can not only improve the welding efficiency, but also obtain the high quality welding joint. This special welding technology could solve the welding problems of Al-Cu dissimilar materials and had a good potential for application in aerospace manufacturing.

You might also be interested in these eBooks

Frontiers of Manufacturing and Design Science II

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 121-126)

Pages:

1707-1711

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.121-126.1707

Citation:

Cite this paper

Online since:

October 2011

Authors:

Xin Zhao, Feng Bo Dong, Guo You Su, Li Jie Guo

Keywords:

Dissimilar Materials, Hybrid FSW (HFSW), Preheating, Weld Quality Improvement

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Metals Handbook. 9th ed. Metals Park, Ohio: ASM international; (1979).

Google Scholar

[2] W.M. Thomas, E.D. Nicholas, J.C. Needham, M.G. Murch, P. Temple-Smith, C.J. Dawes, Friction stir butt welding,: UK, International patent application no. PCTPGB92P02203 and GB patent application (NO. 9125978. 8, 6 December, 1991).

Google Scholar

[3] Elrefaey A, Takahashi M, Ikeuchi K. Weld in the World 2005; 49(3–4): 93–101.

Google Scholar

[4] Pietras A. Weld in the world 2005; 49(9): 122–33.

Google Scholar

[5] W.B. Lee, S.B. Jung. Mater. Res. Innovation 2003; 8(2): 93–96.

Google Scholar

[6] T. Saeid, Abdollah-zadeh, B. Sazgari. Journal of Alloys and Compounds; 490(2010): 652-655.

DOI: 10.1016/j.jallcom.2009.10.127

Google Scholar
