Application of the Block Correction Interpolation Technology in the Ultrasonic Temperature Measurement

Abstract:

A new method about the air temperature reconstruction based on the block correction interpolation was put forward. Its theoretical basis is the principles of thermodynamics relations and ultrasonic temperature measurement. The frequency of ultrasonic generator is 40 KHz. Because of the one-to-one relationship between gas temperature and gas velocity, the gas temperature field can be reconstructed through the rebuilding of velocity field. As the distance between the generator and receiver is known, so the average speed on the path can be obtained by detecting the ultrasonic transit-time. After obtaining the average speed of many paths in the field, the correction of the measured data can be done by using the block correction interpolation technology. And through the mathematical analysis software, the reconstruction of the measured field was given.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 1927-1931
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.1927
• Online since: October 2011
• Authors: Feng Qin Xie, Hua Yu Zhang, Lin Jing Xiao, Hong Chang Ding
• Keywords: Block Correction, Reconstruction, Temperature Field, Ultrasonic

References

[1] Measurement of air temperature distribution based on ultrasonic time of flight Applied Acoustics vol. 29, no. 1, jan., (2010).

[2] New implementation of high-precision and instant-response air thermometer by ultrasonic sensors wen-yuan Tsai, Chih-Feng Huang, Teh-Lu Liao Sensors and Actuators A 117 (2005)88-94 (2004).

DOI: 10.1016/j.sna.2004.06.001

[3] M. Bramanti, E.A. Salerno, A. Tonazzini, S. Pasini, A. Gray, An acoustic pyrometer system for tomographic thermal imaging in power plant boilers, IEEE Trans. On Instrum. Meas. 45 (1996) 159–167.

DOI: 10.1109/19.481329
