Fault Diagnosis of Low Speed, High-Loaded Bearing in Incomplete Rotating State

Abstract:

Signals of Low speed, high-loaded bearings in incomplete rotating state have some characteristics, such as nonstationary, varying load, multi vibration resources and no character frequency. Traditional frequency analytical method can’t solve the problem of fault diagnosis of this kind of bearings. Start with angle domain, a new fault diagnosis method based on characteristics of angle domain is put forward in this paper. And the new feature characteristics, touching frequency and parts contacting angle, are extracted from the vibration signals and rotation signals. This method is applied to diagnose the fault of Low speed, high-loaded bearings in incomplete rotating state. The diagnosis result proves this method is feasible and valid.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 2026-2029
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.2026
• Online since: October 2011
• Authors: Jin Hua Cao, Hai Qi Zheng, Jian Zhuang Zhi, Li Jun Cao
• Keywords: Bearing, Fault Diagnosis, Rotation Signals, Touching Frequency

References

[1] Zhao Pengfei. Fault diagnosis of low speed, high-loaded bearing in incomplete rotating state,. Metallurgy Equipment, vol. 3: pp.40-42.

[2] Gang xiaoye. Fault characteristics and diagnosis discussing of low speed, high-load bearing,. Equipment Management and Maintenance, Vol. 2, pp.12-16, April (1998).

[3] Wang Zhigang. Fault diagnosis of low speed bearing based on harmonic wavelet transformation, Bearing, Vol. 10, pp.37-39 Oct. (2004).

[4] Ai tasman, Hasbargen, and wiegand. Bearing design and application handbook,. Wuchang, Huazhong tech press, (1985).

[5] Liu Zejiu, He Shiquan. Rated load and life of bearing. Beijing, Machinery industry press, pp.66-68, (1982).
