Numerical Simulation of Cold Press Forging Forming for Stepped Hole of Thin Sheet Metal

Abstract:

An optimum process for a two-step press forging of stepped holes in a metal sheet was proposed .Numerical simulation on the two-step process was carried out by using DEFORM-3D. Distributions of effective strain and effective stress were obtained. The study showed that the process not only can form the stepped, but also can increase the surface quality and strength of stepped holes in sheet metal parts, According to the numerical simulation’s process parameter , an experimental die was designed, the simulation results were in good agreement with the experimental data

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 249-253
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.249
• Online since: October 2011
• Authors: Ke Sheng Wang, Jian Lin Liu, Xiao Wei Chen
• Keywords: Cold Press Forging Forming, Numerical Simulation, Stepped Hole

References

[1] Liu X, Cheng K, Webb D. Int. J. Mach. Tools Manuf. Vol. 42(2002), p.791.

[2] Larue A, Auselmetti B. Int. J. Mach. Tools Manuf. Vol. 43(2003), p.129.

[3] Wan M, Zhang W H. J. Mater. Process. Technol. Vol. 171(2006), p.156.

[4] Ratchew S, Liu S, Huang W. J. Mater. Process. Technol. Vol. 153-154(2004), p.134.

[5] Ryu S H, Lee H S, Chu C N. Int. J. Mach. Tools Manuf. Vol. 43(2003), p.1405.

[6] Zhang Luyang. Mould & Die failure and protection . (China machine press, Beijing 1998) , in Chinese.

[7] Wang Jiaying. Mould & Die material and its using life-span. (China machine press, Beijing 2002), in Chinese.

[8] Zhang Xiaoguang, Zhong Zhiping, Yuan Heqiang. Forging & Stamping Technology, Vol. 2(2002), p.16, in Chinese.

[9] Li Hufeng, Lu Xiangfeng. Chinese Journal of Mechanical Engineering, Vol. 44(2008), p.266, in Chinese.
