Design and Implementation on a Novel of Solar Double-Direction Tracking-Device

Abstract:

The development of solar energy tracking technology has important practical significance for promoting solar energy application. In the paper, double-direction tracking-device was designed based on the theory of calendar check tracking and worm gear mechanism, gear transmission mechanism, cam push-rod mechanism was used to achieve the function of “single driving, double-direction tracking” . So, the function of tracking solar azimuth and solar altitude angles was cleverly realized through controlling a single power. In the paper, design and manufacture of the device were completed by Solidworks software. Through the debugging experiment, the device’s advantages were proved of low energy consumption, high reliability, strong anti-interference ability, easy maintenance and suitable for a variety of small solar installations.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 2630-2635
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.2630
• Online since: October 2011
• Authors: Ming Bin Li, Dong Wen Yin, Song Mu
• Keywords: Calendar Check Tracking, Cam Push-Rod, Double-Direction Tracking, Solar

References

[1] Wang Junyi, Xu Renxue, in: Solar Utilization Technology, edited by JinDun Publishing House, Beijing (2008), in press.

[2] Wang Bingzhong: Solar Radiation Calculation Lecture-The Calculation of solar Astronomy Paramenters, Solar Energy, 1999, 2: 8-10.

[3] Mechanical Design Manual, edited by China Machine Press, Beijing (2007), in press.

[4] Zhou Huijun, in: Course Design Manual of Mechanical Design, edited by Higher Education Press, Beijing (1998), in press.

[5] Xue Dingyu, Chen Yangquan, in: MATLAB solution of Advanced Applied Mathematics, edited by Tsinghua University Press, Beijing (2008), in press.

[6] COSMOS Advanced Tutorial, edited by China Machine Press, Beijing (2008), in press.

[7] Liu Fenglong: Study on a novel solar photovoltaic control system (Harbin University of Science And Technology 2010).

[8] Zhang Shanwen, Zhang Jianfeng, Chen Sidong: Design of the Mechanical System of the Sun Ray Two-axis Tracking-device, Mechanical Engineering & Automation, 2010, 4: 91-93.

[9] F. R. Rubio, M. G Omega, F. Gordillo, M. Lopez-Martinez: Application of new control strategy for sun tracking, Energy Conversion and Management, 2007, 48（7）: 2174-2184.

DOI: 10.1016/j.enconman.2006.12.020

[10] Liao Jincheng: The Study of Computer Controlled Two-Axis Solar Tracking System and Its Error Measurement (WuHan University of Technology 2008).

[11] Liang Yong, Liang Weiming: The Model Simulation of Solar Azimuth Automatic Tracking Accuracy Optoelectronic Technology, 2008, 28(3): 170-173.
