Intelligent Correction of Shift Schedule for Dual Clutch Transmissions Based on Different Driving Conditions

Abstract:

This paper focuses on intelligent correction of shift schedule for dual clutch transmissions based on different driving conditions. The problem of standard shift schedule has been presented, and the strategy has also been proposed to avoid shift hunting and unexpected shift. The driver’s intention and driving environment have been unified recognized as different driving conditions. A fuzzy logic technology has been used in driver’s attention recognition based on the throttle opening and its derivative. The standard shift schedule has been intelligently corrected at different driving condition separately. An algorithm based on correction coefficient of throttle opening and vehicle speed is proposed for intelligent correction. The corrected shift schedule can be directly used in real time shift control with suitable correction coefficient.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 3982-3987
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.3982
• Online since: October 2011
• Authors: Yong Gang Liu, Da Tong Qin, Zhen Zhen Lei, Rui Ding
• Keywords: Driving Condition, Dual Clutch Transmissions, Intelligent Correction, Shift Schedule

References

[1] Matthes, B., 2005, "Dual Clutch Transmissions – Lesions Learned and Future Potential," Proceeding of Transmission and Driveling Systems Symposium-4WD/AWD, SAE paper No. 2005-01-1021.

DOI: 10.4271/2005-01-1021

[2] Wheals, J., Turner, A., Ramasy, K., O'Neil, A., 2007, "Double Clutch Transmission (DCT) Using Multiplexed Linear Actuation Technology and Dry Clutches for High Efficiency and Low Cost," SAE paper No. 2007-01-1096.

DOI: 10.4271/2007-01-1096

[3] X. Yin, J. Tan, Y. Lei, and A. Ge, "Research on a Neural Network Model Based Automatic Shift Schedule with Dynamic 3-Parameters," SAE paper No. 2005-01-1597.

DOI: 10.4271/2005-01-1597

[4] H. Yamaguchi, Y. Narita, H. Takahashi, and Y. Katou, "Automatic Transmission Shift Schedule Control Using Fuzzy Logic," SAE paper No. 930674.

DOI: 10.4271/930674

[5] Zhang Z, Zhao D, Sun B. Study on Fuzzy Automatic Transmission Strategy of vehicles. Proceedings of IEEE Conference on Cybernetics and Intelligent Systems, 21-24 Sept. 2008 Page(s):1359~1363.

DOI: 10.1109/iccis.2008.4670744

[6] G. Qin, A. Ge, and J. Lee, "Knowledge-Based Gear Position Decision," IEEE transaction on intelligent transportation systems, Vol.5, No.2, June 2004, pp.121-126.

DOI: 10.1109/tits.2004.828171

[7] X. Guo, C. Fu, F. Cheng, J. Yan, and Z. Yin, "Modeling and Simulation Research of Dual Clutch Transmission Based on Fuzzy Control," SAE paper No. 2007-01-3754.

[8] Kulkarni, M., Shim, T., and Zhang, Y., 2007, "Shift Dynamics and Control of Dual-Clutch Transmissions," Mech. Mach. Theory, 42(2), p.168–182.

DOI: 10.1016/j.mechmachtheory.2006.03.002

[9] Yonggang Liu, Datong Qin, Hong Jiang, et al. Shift Schedule Optimization for Dual Clutch Transmissions. IEEE Vehicle Power and Propulsion Conference, 2009 Sep.7-11:1071-1078.

DOI: 10.1109/vppc.2009.5289728
