Node Design of Alarming System for Coal Gas Based on AT89C55WD and CAN Bus

Abstract:

According to the performance and features of AT89C55WD and CAN bus, a nod design method of alarming system for coal gas based on AT89C55WD and CAN bus is proposed in this paper. The hardware structure and the design process of software are discussed in detail. The hardware system consists of microprocessor AT89C55WD, CAN controller SJA1000 and CAN transceiver PCA82C250. Under the support of corresponding software, the gas density, temperature and humidity can be effectively monitored by this alarming system.

• Periodical: Applied Mechanics and Materials (Volumes 121-126)
• Pages: 999-1003
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.121-126.999
• Online since: October 2011
• Authors: Ying Jiang Han, Zhi Yuan Chen
• Keywords: AT89C55WD, CAN Bus, Coal Gas Monitoring, Node Design

References

[1] Zenghuan Liu: Coal Mine Machinery, Vol. 29, NO. 9 (2008), pp.153-155, in Chinese.

[2] Fang Han: Coal Mine Machinery, Vol. 30, NO. 2 (2009), pp.142-144, in Chinese.

[3] PHILIPS Semiconductors Product specification: SJA1000 Stand-alone CAN controller (2000), pp.4-6.

[4] PHILIPS Semiconductors Product specification: application note PCA82C250/251 CAN transceiver (2000), pp.8-10.

[5] Yingjiang Han, Ying Yun: Electric Power Automation Equipment, Vol. 27NO. 6 (2007), pp.95-98, in Chinese.

[6] Liming He：Designing in Single Chip Application System（Beijing University of Aeronautics and Astronautics press, Beijing 1990）, in Chinese.

[7] Haixia Li：Coal Mine Machinery, Vol. 27NO. 5 (2006), pp.757-759, in Chinese.
