Research on PID Control Model for Error Compensation in Milling Thin-Wall Parts

Abstract:

Accuracy of machined components is one of the most critical considerations for any manufacturer. To improve the accuracy by diminishing errors in CNC milling thin-wall parts, this article analyzes sources of errors and provides PID control model to error compensation, namely acquiring offset value by calculating the coefficients of proportional, integral and differential and corresponding errors, and then adjusts codes of next processes. The effectiveness of PID control model in improving accuracy is testified by experiments contrasting with groups of non-compensation and completely-compensation. The experiments have proved that PID control model of CNC milling thin-wall parts can predict machining error trends and have advance regulation.

• Periodical: Applied Mechanics and Materials (Volume 127)
• Pages: 522-526
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.127.522
• Online since: October 2011
• Authors: Lei Zhu, Jun Lu, Yan Liu
• Keywords: CNC Milling, Error Compensation, PID Control Model, Thin-Wall Parts

References

[1] Jinxin Kong, Dajiang Lei, Xiaobin Yue, High Speeh Milling Experiment for Thin-wall Workpiece, J. MACH INE TOOL & HYDRAUL, 2008 (3) 52-55.

[2] S. Ratchev, S. Liu*, A.A. Becker, Error compensation strategy in milling flexible thin-wall parts, J. Materials Processing Technology, 162-163 (2005) 673-681.

DOI: 10.1016/j.jmatprotec.2005.02.192

[3] Jun Lu, Yu-Mei Huang, Yang Liu, Wen-wen Li, and Hua Zhong, Study on Workpiece Machining Precision PID Control Model in Closed-loop Manufacturing Systems, J. Key Engineering Materials, 419-420 (2010) 469-472.

DOI: 10.4028/www.scientific.net/kem.419-420.469

[4] Xiaohong Zhou, Source of errors and countermeasure of digital control processing, J. Manufacturing Automation, 2002 (8) 20-23.
