The Research about the Inverse Kinematic of the Tricept Mechanism Based on Pro/Engineer

Abstract:

The mathematical modeling and the kinematic simulation of the Tricept mechanism are finished by using the Pro/Engineer software in this paper. On the basis of the movement trajectory of the end point of the mechanism, the inverse kinematic and the kinematic curve of the Tricept mechanism are get, which are the basis of the control about the drive mechanism. In the meaning time, under using the Pro/Engineer, it is possible for us to control the motion of the end-point of mechanism which moved on the tangential plane. In order to avoid the tool to shimmy, the cutting output is constant in the course of processing which improves the process precision of the complex parts and provides the feasible and effective method for us to process the complex aerospace parts.

• Periodical: Applied Mechanics and Materials (Volumes 130-134)
• Pages: 1132-1136
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.130-134.1132
• Online since: October 2011
• Authors: Xiao Hua Huang, Jian Cheng Xu, Wei Dai, Chun Song Wang
• Keywords: Control of Position, Control of Status, Inverse Kinematic, Modeling, Simulation, Tricept Mechanism

References

[1] Shanjun Chen, Yuanlou Gao. In: The analysis about the inverse kinematics of the Tricept, The Symposium Proceedings of the Aviation Institute Hydraulic Pneumatic of China. ( 2005).

[2] Jianfeng Li, Xinhua Wang, etal. In: The cutter trajectory programming of the Tricept, The academic journal of Beijing University of Technology. Bei Jing, 2002(12). Vol. 28-4.

[3] Tsai L.W., etal. In: A comparison study of Two 3-DOF parallel Manipulators One with Three and the Other With Four Supporting Legs, IEEE. (2002).

DOI: 10.1109/robot.2002.1014283

[4] Dan Zhang, etal. In: Kinetostatic Analysis and Design Optimization of Tricpt Machine Tool Family. (2002).

[5] Tsai, L.W., etal. In: Robot Analysis: The Mechanics of Serial and Parallel Manipulators, edited by Join Wily&Sons, New York. (1999).
