Study on Combine Harvester Speed Control Based on Optimum Threshing Power Consumption Model

Abstract:

Combine harvester have to be operated in a wide range of field condition which may induce varying feeding rate. Forward speed is a main variable to control the feeding rate of combine harvester for high efficiency. In this study a control strategy based on optimum threshing power consumption model was developed and integrated into a speed control system for combine harvester automation. A conventional self-propelled combine harvester (Xinjiang-II) was equipped with multiple sensors to collect online information, including forward speed, threshing drum torque and speed. Forward speed was then adjusted by an electric-hydraulic unit based on designed PID controller to achieve an optimum range of threshing power consumption. Field test was conducted to evaluate the performance of the controller under variable feeding rate condition. From obtained results, the controller can improve the efficiency of tested machine during field operation.

You might also be interested in these eBooks

Mechanical and Electronics Engineering III

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 130-134)

Pages:

1911-1914

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.130-134.1911

Citation:

Cite this paper

Online since:

October 2011

Authors:

Du Chen, Feng Kang, Qing Yuan Zhu, Shu Mao Wang

Keywords:

Combine Harvester, Mathematical Models, Speed Control, Threshing Power Consumption

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Zhan Jie, Hongjun Liu, Fengyun Hou: J Henan University of Science and Technology, Vol. 25(3) (2004), p.1.

Google Scholar

[2] T. Kawamura, N. Kawamura and K. Namikawa: J Soc. Agri. Machinery, Vol. 39(2) (1977), p.157.

Google Scholar

[3] P.B. Anderson, U.S. Patent 3, 073, 099. (1963).

Google Scholar

[4] M. J. Le Flufy and G. T. Stone: J Agri. Engineering Research, Vol. 28(6) (1983), p.537.

Google Scholar

[5] S.D. Pool and T.A. Middlesworth, U.S. Patent 3, 546, 860. (1970).

Google Scholar

[6] J.W. Kruse, G.W. Krutz, L.F. Huggins, U.S. Patent 4, 487, 002. (1984).

Google Scholar

[7] Shumao Wang, Qingyuan Zhu, Feng Kang, Du Chen, Zushen Liu, Hai Teng, China Patent ZL200810115081. (2009).

Google Scholar

[8] Feng Kang, Shumao Wang, Qingyuan Zhu, et al. Model analysis of threshing power consumption for combine harvester based on computer measurement system[C]. In: International Conference on Computers, Communications, Control and Automation, Hong Kong, China, (2011).

Google Scholar
