Key Factors in Fiber Point Diffraction Interference Technology for Measuring Surface

Abstract:

The point diffraction interferometer (PDI), which generates the nearly ideal spherical wavefront with the pinhole method, is realized the absolute interferometric measurement without the use of reference surface. But it is hard to detect the diameter of the pinhole and hard for use of phase shifting interferometers in PDI. However the advanced fiber point diffraction interferometer (FPDI) not only replaces the pinhole with the fiber, but also makes it possible to implement phase shifting and maintain advantage of traditional PDI. In this paper, the different methods of measuring surface are proposed according to different experimental conditions and different targets (such as concave spherical surface, convex spherical surface, flat surface) with the fiber point diffraction interferometer built in the laboratory. Base on these experiments, there are several key factors in the measurement process such as measurement configuration, laser source, polarization beamsplitter, optical fiber. And these factors, affecting the experiment accuracy, were analyzed seriously.

• Periodical: Applied Mechanics and Materials (Volumes 130-134)
• Pages: 4045-4048
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.130-134.4045
• Online since: October 2011
• Authors: Jie Li, Ling Feng Chen
• Keywords: Fiber Point Diffraction, Optical Fiber, Optical Measurement, Surface Measurement

References

[1] K. Otaki, F. Bonneau, et al. Absolute Measurement of spherical surface by point diffraction interferometer. Proceedings of SPIE, Vol. 3740, pp.602-605, (1999).

[2] Smartt R N, Strong J. Point Diffraction Interferometer. Opt. Soc. Am (S0740-3232), Vol. 62, pp.737-742, (1974).

[3] Smartt R N, Steel W H. Point diffraction interference microscopy. Applied Optics, Vol. 24, pp.1402-1403, (1979).

[4] Liu Guogang, Zhang Xuejun, et al. Fiber point diffraction interferometer. Optics and Precision Engineering, Vol. 9, pp.142-145, 2001. (in Chinese).

[5] Pierre M. Lane, Michael Cada, et al. Optical fourier processor and point-diffraction interferometer for moving-object trajectory estimation. Applied Optics, Vol. 38, pp.4306-4315, (1999).

DOI: 10.1364/ao.38.004306

[6] Qian Gong, M. Geary, et al. Modeling point diffraction interferometers. Society of Photo-Optical Instrumentation Engineers, Vol. 35, pp.351-356, (1996).

[7] Gary E. Sommargren, Donald W. Phillion, et al. 100-Picometer Interferometry for EUVL. Proceedings of SPIE, Vol. 4688, pp.316-328, (2002).

[8] Lingfeng Chen, Yaqing Ren, Jie Li. Flat surface measurements on fiber point diffraction interferometer. Opt. Eng. , Vol. 49: 050503, (2010).

DOI: 10.1117/1.3432575

[9] Lingfeng Chen, Liang Nie, Taogeng Zhou, Dingguo Sha. Research on the fiber point diffraction interferometer for spherical figure measurement. Proceedings of SPIE, Vol. 6357: 63574J, (2006).
