Research of a Driving Equipment for Aero-Engine Rotor Based on FPGA

Abstract:

The positioning accuracy can bring a great impact on inspecting defect for Aero-engine blade. The high or low pressure rotor of engine is generally driven by manual when blade’s defect is inspected. Frequently，False detection and missed happens due to match failure between two persons. Adopting a high-resolution, high-accuracy algorithm based on FPGA to design automotive equipment for high or low rotor . The Frequency range to step motor is 1Hz / s to 65536Hz / s, resolution is 1Hz,and positioning accuracy for blade can be up to 1mm.Resolving the questions of missing detectable rates made by manual during inspection in the paper, and increasing efficiency for inspection and the reliability of the experimental result. Experiment results show that this equipment can meet the challenge of the high-accuracy regulating speed for blade’s inspection.

• Periodical: Applied Mechanics and Materials (Volumes 135-136)
• Pages: 725-731
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.135-136.725
• Online since: October 2011
• Authors: Li Min Wen, Chang Bao Wen, Yan Ming Li
• Keywords: Blade Inspection, Field-Programmable Gate Array (FPGA), High Resolution Pulse, Step Motor

References

[1] GUAN Yu-pu, CHEN Wei , GAO De-ping. Present Status of Investigation of Foreign Object Damage to Blade in Aeroengin, ACTA AERONAUTICA ET ASTR0NAUTICA SINICA. Vol 28, 2007, pp.851-857.

[2] CHEN Wei, GUAN Yu pu, GAO De ping. Numerical Simulation of the Transient Response of Blade due to Bird Impact, ACTA AER0NAUTICA ET ASTR0NAUT ICA SINICA. Vol 24 , Jun, 2003, pp.531-533.

[3] Bodson M, Chiasson J. Novotnak RT, Rekowski RB. High performance nonlinear feedback control of a permanent magnet stepper motor. IEEE Trans Control Syst Technol 1993, 1(1): 5-13.

DOI: 10.1109/87.221347

[4] Yang HH, Zhang C, Chen AC, The Implementation of Constant Torque Microstepper Driving Circuit for Stepping Motor, Electron Technol, Vol 18, 2000, pp.65-9.

[5] WANG Xiao ming. Singal Chip Microcomputer to Step Control , Press of Beihang University, Beijing ，2002: 194-201.

[6] Armando Astarloa, Unai Bidarte, FPGA Technology for Multi-axis Control Systems , Mechatronics 19(2009): 258-268.

DOI: 10.1016/j.mechatronics.2008.09.001

[7] DU Gang, Sun Chao, Chen An jun. Design of Sixteen Bits Digital Frequency Divider Based on FPGA, Vol 27, Jun, 2006，pp.875-876.

[8] Xiao yin Shao, Dong Sun. Development of an FPGA based motion control ASIC for robotic manipulators,. In: Proceedings of the IEEE the sixth world congress on intelligent control and automation, vol. 2; Jun 2006, pp.8221-5.

DOI: 10.1109/wcica.2006.1713577

[9] JIANG Li dong． Design and Application of VHDL,. Press of Beihang University. Beijing : 2004: 93-192.
