Dynamic Mechanism Research and Seismic Simulation Experimentation on Superconducting Busbar of the ITER

Abstract:

To study the dynamic mechanism on ITER (International Thermonuclear Experimental Reactor) superconducting Busbar, the seismic response time-history analysis and seismic simulation experimentation had been done respectively. After choice of seismograms with seismic amplitude, spectrum, duration and ground conditions comprehensively, the structural response curves and response duration results of displacement, tensile stress, and reaction force under different directions actuating signals were obtained by using the time-history analysis. To test the accuracy of simulation analysis, the seismic simulation experimentation of the reduced experimental model of Busbar on the vibration table had been adopted with similitude ratios and conditions designing based-on the similarity theory. The accuracy of simulating analysis had been examined to satisfy the requirements of designed similitude ratios about displacement, acceleration and strain.

• Periodical: Applied Mechanics and Materials (Volume 141)
• Pages: 114-118
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.141.114
• Online since: November 2011
• Authors: Kai Song Wang, Yun Tao Song
• Keywords: Accuracy, Dynamic Mechanism, ITER Superconducting Busbar, Ratio Law of Similitude, Seismic Response Time-History Analysis, Vibration Experimentation Table of Simulating Earthquake

References

[1] ITER Organization. 2005, Design Description Document DDD 11 Magnet 1. 3-Procurement Packages Annex 5 (Feeders), France: ITER Organization, N 11 DDD 118 01-07-09 R 0. 1.

[2] ITER Organization. 2005, Design Description Document DDD 11 Magnet, France: ITER Organization, N 11 DDD 142 01-07-12 R 0. 1.

[3] WANG K. S., ZHAO H., SONG Y. T.: Nuclear Fusion and Plasma Physics Vol. 4 (2007) No. 27 , pp.315-319.

[4] Gao M. T., Pan H., Yu Y. X.: Recent Developments in World Seismology Vol. 9 (2004) No. 309, pp.26-32.

[5] Vladimir S., Seismic Analysis of the ITER Tokamak with wave-propagation Rocking Effect with SSI and the Building Simulator in the Candidate Sites, France: ITER Organization, Sorin Seismic MEMO 15 April (2005).

[6] Fuji company: Design Of Current Leads and Superconducting Busbars System, Japan, (1997).

[7] Participant Team of China. Design and Analysis of Magnet Feeders, China: ASIPP. Task Report of Task N11 TD 106FP, (2006).

[8] ZHOU M. L.: Similar Engineering Science (China Machine Press, Beijing 1998).
