Analysis of C80B Wagon’s Load-Stress Transfer Relation

Abstract:

In this paper, C80B car body is the research object to study the load-stress transfer relationship that has great influence on the car body structure. First of all, through the test data of line DaTong to Qin Huangdao, the load-time history of C80B car body’s load on center plate, load on draw gear, roll load and torsional load have been obtained, as well as the stress-time history of the body fatigue key parts have been obtained. And the load spectrum and stress spectrum have been made up. Then the finite element analysis of the car body is made. The load-stress transfer coefficient of fatigue key parts on car body could be obtained. Last the load and stress transfer relationship in detail considering the measured data has been analyzed.

• Periodical: Applied Mechanics and Materials (Volumes 148-149)
• Pages: 331-335
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.148-149.331
• Online since: December 2011
• Authors: Yu Qing Yuan, Qiang Li, Kun Ran
• Keywords: C80B Wagon, Finite Element, Load Spectrum, Load-Stress Transitive Relation, Stress Spectrum

References

[1] Naicun Xue. The Effect of Chinese Railway Speed increase Analysis [D]. Master's degree thesis of Beijing JiaoTong University. 2010. 7. 24-27.

[2] Weixing Yao. Fatigue Life Analysis of Structures [M]. Beijing: National Defence Industrial Press. 2003: 4-10.

[3] Jilong Xie. Reliability Evaluation of Structures [M]. Beijing：China Machine Press. 2007: 5-9.

[4] Wenmiao Dang. Fatigue analysis about the key positions of T20, 000 Marshalling C80B Gondola Car[D]. Master's degree thesis of Beijing JiaoTong University. 2010. 7. 12-14.
