Design of the Several Pneumatic Tendon Piston

Abstract:

With the rapid development of hydraulic technology, pressure-driven piston pump, the output pressure, simple structure, in the field of mechanical engineering and field engineering work has been widely used. For existing pneumatic piston existence of a functional insufficiency, poor technical performance, the irrational structure, and high-pressure areas, especially in high pressure areas occupy an irreplaceable position in the axial and radial piston pumps, there are also complex, expensive, traffic pulse rate not ideal and other indicators of disadvantage. In this paper, the normal replacement method for flexible-rigid pneumatic cylinder replacement tendons, structural design, light weight, is able to adapt to harsh environments tendon type pneumatic piston. Practical results shows that the design of the pneumatic piston in the wild-type tendon in applied engineering work obtains good results.
