The Determination and Simulation of Boom's Reasonable Derricking Acceleration

Abstract:

Derricking device of flexible transmission is widely applied in crawler cranes, while its derricking speed hasn't been studied very well. In this paper, the kinematics model of derricking device is firstly established. Next, the dynamic analysis is done. A succinct method based on the load's prescriptive swing angle is put forward. The reasonable speed and acceleration of derricking device are determined according to the method. The adopted values provide a reliable basis for design and analysis. The study puts a way for the following work. All in all, it is innovative.

• Periodical: Applied Mechanics and Materials (Volumes 16-19)
• Pages: 623-627
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.16-19.623
• Online since: October 2009
• Authors: Gui Yu Lin, Wei Liang Li, Kui Xian Li
• Keywords: Crane, Derricking Device, Dynamic, Kinematics, Optimization Design

References

[1] I.I. Kogan: Building Tower Crane ( In Russian) (Machine Press, Moscow 1958).

[2] E.K. Senda: Transactions of the Japan Society of Mechanical Engineers (In Japanese), Vol. 42 (1951) No. 358, pp.1727-1732.

[3] D.M. Gu: Construction Crane (In Chinese) (China Architecture & Bilding Press, China 1988).

[4] C.K. Yang: Crane Machinery (In Chinese) (China Machine Press, China 1982).

[5] H.Z. Wu and D.M. Gu: Calculation and Design of Crane (In Chinese) (Beijing Science & Technology Press, China 1989).
