Study of Aerodynamic Interactions of Dual Flapping Airfoils in Tandem Configurations

Abstract:

The unsteady viscous flow fields of dual flapping airfoils in tandem configurations are simulated by a Navier-Stokes Solver based on dynamic deformable hybrid meshes. Aerodynamic interactions of three motion models are studied including flapping fore airfoil with fixed aft airfoil, two airfoils flapping in phase and out-of-phase. The results indicate that the aft airfoil in the wake of the flapping fore airfoil has great influence on the aerodynamic performance. When the fore airfoil flaps with a fixed aft airfoil, the thrust generation and thrust propulsive efficiency were enhanced by 65% and 44% respectively, compared to that of single flapping airfoil. When the two airfoils stoke in phase, the thrust generation is twice over that of single flapping airfoil. However the out-of-phase stroking has relatively much lower thrust.

• Periodical: Applied Mechanics and Materials (Volume 160)
• Pages: 301-306
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.160.301
• Online since: March 2012
• Authors: Bao Li Zhu, Hui Pen Wu, Tian Hang Xiao
• Keywords: Aerodynamic Interaction, Flapping Wing, Micro Air Vehicle (MAV), Navier-Stokes Equation

References

[1] Lai J C S, Platzer M F. The Characteristics of a Plunging Airfoil at Zero Free-Stream Velocity[J]. AIAA Journal, 39(3): 531-534 (2001).

DOI: 10.2514/3.14764

[2] Hubel T Y, Tropea C. Experimental investigation of a flapping wing model[J]. Exp Fluids, 46: 945–961(2009).

DOI: 10.1007/s00348-008-0599-9

[3] Anderson J M, Streitlien, K, Barrett D S. Oscillating Foils of High Propulsive Efficiency[J]. Journal of Fluid Mechanics, 360: 41-72(1998).

DOI: 10.1017/s0022112097008392

[4] Schmidt W. Der wellpropeller ein neuer antrieb fuerwasserland, und luftahrzeuge[J]. Z. Flugwiss, 13: 472-479(1965).

[5] Bosch H. Interfering Airfoils in Two-Dimensional Unsteady Incompressible Flow[J]. ARARD-CP-227(1978).

[6] Kwanjung Y, Wandon J. Thrust Generation by Simultaneous Flapping Airfoil in Tandem Configuration[J]. AIAA Paper 2006-2838.

[7] Lan S L, Sun M. Aerodynamic Force and Flow Structures of Two Airfoils in Flapping Motions[J]. Acta Mechanica Sinica, 17: 310-331(2001).

DOI: 10.1007/bf02487459

[8] Wang J K, Sun M. A Computational Study of the Aerodynamics and Forewing-Hindwing Interaction of a Model Dragonfly in Forward Flight[J]. The Journal of Experimental Biology, 208: 3785-3804(2005).

DOI: 10.1242/jeb.01852

[9] Liu X Q, Qin N. Fast Dynamic Grid Deformation Based on Delaunay Graph Mapping[J]. Journal of Computational Physics, 211: 405-423(2006).

DOI: 10.1016/j.jcp.2005.05.025

[10] Tuncer I H, Kaya M. Thrust Generation Caused by Flapping Airfoils in a Biplane Configuration[J]. Journal of Aircraft, 40(3): 509-515(2003).

DOI: 10.2514/2.3124

[11] Miao J M, Ho M H. Effect of Flexure on Aerodynamic Propulsive Efficiency of Flapping Flexible Airfoil[J]. Journal of Fluids and Structures, 122: 401-419(2006).

DOI: 10.1016/j.jfluidstructs.2005.11.004
