Research on Application of NC Polish-Grinding of Valve Stem and Instantaneous Compensation of Grinding Wheel

Abstract:

According to the example of using a common grinding and composition of parts processing movement and achievement elements, the design of construction of special NC technologies in ordinary grinding machine was formulated. . The grinding and polish-grinding were performed by using two NC systems in series to achieve multi-axis movement. The function and application scope of NC technology were expanded because the instantaneous compensation of the grinding wheel and the polish-grinding wheel were performed under a rectangular coordinate system and a polar coordinate system by using an open loop NC system. The application of surface recovery of grinding wheel by NC reconstruction and extension applications of processing the track of involute curve were referred.

• Periodical: Applied Mechanics and Materials (Volume 163)
• Pages: 191-195
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.163.191
• Online since: April 2012
• Authors: Ying Liang Yu, Zhan Li Huang, De Qing Yang, Zhi Yi Miao
• Keywords: Grinding, Instantaneous Compensation of Grinding Wheel, Polish-Grinding, Special NC Reconstruction, Surface Recovery of Grinding Wheel

References

[1] Zhang X.Y., Design of Economic NC Machine Tools , China Machine Press, Beijing, (1994).

[2] Lin Q.J., Design of Mechanical System Controlled by Microcomputer, Shanghai Scientific & Technical Publishers, Shanghai, (1991).

[3] Yu,Y.L., Design and Examples of NC Reconstruction of Machine Tools, China Machine Press, Beijing, (1998).
