Measurement of Armature Components' Synthetic Stiffness Based on Torque and Grating Ruler Sensor

Abstract:

The synthetic stiffness measurement principle of Armature Components which is similar to the actual working condition has been proposed. The synthetic stiffness measurement system based on the measurement principle has been established, the composition of this system has been introduced and the realization methods of the single couples loading and torque and angle measurement has been introduced in detail. And related experiments has been conducted. Through analysis the experiment data, the performance of organization has been tested, and so does the rationality of the measurement principle which is proposed.

• Periodical: Applied Mechanics and Materials (Volume 163)
• Pages: 201-206
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.163.201
• Online since: April 2012
• Authors: Qi Wen Zeng, Hui Feng Wang, Guang Lin Wang
• Keywords: Armature Components, Composite Stiffness, Electro-Hydraulic Servo Valve, Measurement

References

[1] G.R. Ren, Z.H. Zhang, Y.Q. Zhou: Manufacture technics of electro-hydraulic servo valve, edtied by China Astronautic Publishing House, Pekin, CHINA (1988), pp.2-59.

[2] G.L. Wang: Research on automatic measurement and control of machining quality of servo valve orifice. (Ph.D., Harbin Institute of Technology, China 2000). 2000, pp.1-8.

[3] Y.D. Tian: Electro-hydraulic servo valve technology. edtied by China Aviation industry press, Pekin, CHINA (2008), pp.11-13.

[4] H.F. Wang, G.L. Wang and Z.S. Lu: Applied Mechanics and Materials, Vol. 42(2011), pp.471-475.

[5] H.F. Wang, G.L. Wang and Q.W. Zeng: Advanced Materials Research Vol. 305 (2011) pp.117-121.
