Mechanical Property Analysis on Joints of Steel Secondary Beam Inserted in Reinforced Concrete Frame Girder

Abstract:

Models for internal force analysis and strain distribution of joints of steel secondary beam inserted in reinforced concrete frame girder were analyzed. The horizontal internal force and vertical force were considered separately during calculation and analysis process. Bending-shearing correlation of vertical internal force was studied while the horizontal force wasn’t taken into account. Results show that the non-dimensional moment varies linearly with the non-dimensional shear force. Base on this, the formulas by which the joint moment and shear force are calculated are derived, and are related to depth ratio of forward to backward compression zone .And then the method to calculate joint moment capacity under horizontal force is put forward. By investigating the moment and shear force variation, the relationship between the yielding stress of the bar in the slab and the boundary concrete under the steel secondary beam crushing is identified. In the end, practical design method is proposed, and problems need further research are mentioned.

• Periodical: Applied Mechanics and Materials (Volumes 166-169)
• Pages: 3087-3094
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.166-169.3087
• Online since: May 2012
• Authors: Qiong Yu, Jian Li Xu, Xing Zhuang Zhao
• Keywords: Bending-Shearing Correlation, Depth of Compression Zone, Internal Force Model, Joint Moment, Joint Shear Force

References

[1] Huiliang Xu. Study on static behavior of joint of steel sub-beam and concrete beam [D], Harbin Institute of Technology, 2009. (in Chinese)

[2] Qiong Yu, Zhoudao Lu, Jiangtao Yu. Experimental study on connection of steel secondary beam embedded in reinforced concrete girder of frame structure. Civil Engineering, Architecture and Building Conference,2011,Haikou, China.

DOI: 10.4028/www.scientific.net/amr.243-249.1072

[3] Qingfa Yang, Wenke Qin, Jianbo Zhou. Experimental study on the joint connection of unilateral steel timbers inserted into the concrete girder. [J]. Journal of Civil Engineering and Management,2011,28(1):53-58. (in Chinese)

[4] Qingfa Yang,Wenke Qin,Jianbo Zhou ,etc. Experimental study on the joint connection of unilateral steel timbers inserted into the concrete girder.[J].Construction Technology,2011,40(346):75-78.

[5] Xianglin Gu. Basic principles of concrete structures. Shanghai: Tong University Press.2004. (in Chinese)

[6] Shansuo Zheng, Yong Yang, Jianyang Xue, etc. A review on the bond-slip behaviors of SRC structures.[J]. Journal of building structures, 2005,26(4):1-9(in Chinese)

[7] MarcakiS K, Mitchell D. Precast concrete connections with embedded steel members. Journal Pre-stressed Concrete Institute 1980;25(4):86-116 .

DOI: 10.15554/pcij.07011980.88.116

[8] Code for design of concrete structures .GB 50010-2010.Beijing:：China architecture and Building Press.(in Chinese)
