Cyclic Behavior of High Strength Steel H-Shaped Beam

Abstract:

This study is intended to show possibility of using high strength steel for H-shaped beams with large depth-thickness ratio in the elastic range by conducting loading tests. Test specimens are manufactured with high strength steel of over 700N/mm2 yield stress. Elastic behaviors of such beams under cyclic loading are mainly concerned. In addition, the redundancy and the stability of these beams in plastic range are investigated. It is shown that these beams are useful as seismic design beams although the depth-thickness ratio of H-shaped beams is larger than the limit of current standards in Japan. Also, by referring to a recent study, a new limit value of plate slenderness ratio (depth-thickness ratio of web plate and width-thickness ratio of flange plate) is proposed.

You might also be interested in these eBooks

Advanced Building Materials and Sustainable Architecture

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 174-177)

Pages:

159-165

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.174-177.159

Citation:

Cite this paper

Online since:

May 2012

Authors:

Takuma Shinohara, Ryota Suekuni, Kikuo Ikarashi

Keywords:

Collapse Mode, Cyclic Loading, Depth-Thickness Ratio, High Strength Steel (HSS), H-Shaped Beam

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Architectural Institute of Japan: Design Standard for Steel Structures -Based on Allowable Stress Concept- (AIJ, Japan 2005)

Google Scholar

[2] Architectural Institute of Japan: Recommendation for Limit State Design of Steel Structures (AIJ, Japan 2010)

Google Scholar

[3] T. Suzuki, K. Ikarashi, T. Azuma and K. Satsukawa: A Study on Large Deformation Behavior of High Strength Steel Beams with Large Depth-Thickness Ratio, Journal of structural and construction engineering, Architecture Institute of Japan No.504 (1998), pp.95-101

DOI: 10.3130/aijs.63.95_1

Google Scholar

[4] K. Ikarashi and T. Wang: Evaluation of width-thickness ratio limitation of H-shaped beam members based on coupled buckling analysis, Journal of structural and construction engineering, Architecture Institute of Japan No.629 (2008), pp.1177-1184

DOI: 10.3130/aijs.73.1177

Google Scholar

[5] T. Suzuki, T. Ogawa, K. Ikarashi and M. Obata: Evaluation of the Plastic Deformation Capacity Modified by the Effect of Ductile Fracture, Behaviour of Steel Structures in Seismic Areas, STESSA (1997), Kyoto, Japan, pp.326-333

Google Scholar
