A New Current-Mode Multiphase Sinusoidal Oscillator Using Adjoint Op-Amp

Abstract:

In order to get current-mode multiphase sinusoidal oscillator with high frequency, high accuracy, high stability and easy to be integrated, a multiphase sinusoidal oscillator circuit is presented. The oscillator can produce N output-currents (N being even or odd) with equal-amplitude and equal- phase spaced. The circuit uses adjoint Op-Amp, grounded capacitors and enjoys low passive sensitivities. The oscillation condition and frequency for the oscillator can be tuned independently. The simulated results are illustrated.

• Periodical: Applied Mechanics and Materials (Volumes 182-183)
• Pages: 486-490
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.182-183.486
• Online since: June 2012
• Authors: Yon Gan Li, Zhan Ting Fan, Xuan Ni Zhang
• Keywords: Adjoint OP-Amp, Current-Mode Circuit, Multiphase Sinusoidal Oscillator

References

[1] D. S. Wu, S. I. Liu and Y. S. Hwang: Multiphase sinusoidal oscillator using second-generation current conveyors. Int. J. Electron, Vol. 78 (1995), p.645–651.

DOI: 10.1080/00207219508926198

[2] C. L. Hou and B. Shen: Second-generation current conveyor-based multiphase sinusoidal oscillators. Int. J. Electron, Vol. 78 (1995), p.317–325.

DOI: 10.1080/00207219508926165

[3] D. S. Wu, S. I. Liu, Y. S. Hwang and Y. P. Hu: Multiphase sinusoidal oscillator using the CFOA pole. IEE Proc. Circuits, Devices and systems, Vol. 142 (1995), p.37–40.

DOI: 10.1049/ip-cds:19951682

[4] M. T. Abuelma'atti: Current-mode multiphase oscillator using current followers. Microelectron, Vol. 25 (1994), p.457–46.

[5] M. T. Abuelma'atti and M. A. Al-Qahtani: A New Current-Controlled Multiphase Sinusoidal Oscillator Using Translinear Current Conveyors. Analog and digital signal processing, Vol. 45 (1998), p.881–885.

DOI: 10.1109/82.700937

[6] W. Tangsrirat and W. Tanjaroen: Current-mode multiphase sinusoidal oscillator using current differencing transconductance amplifiers. Circuits syst signal process, Vol. 27 (2008), p.81–93.

DOI: 10.1007/s00034-007-9010-y

[7] S. C. Qin and Q. Y. Gao: Modern analog integrated electronics, Bei jing: Science Press, 2003, p.10–17. （in Chinese）.

[8] Y. A. Li: Multifunctional second-order current-mode filter based on AOA and its computer simulation. Electronic components & materials, Vol. 26, No. 2 (2007), p: 61–63. （in Chinese）.

[9] Y. A. Li: Realization of higher-order current-mode filter with generalized impedance converter based on AOA's. Chinese journal of electron devices, Vol. 30, No. 3 (2007), p.849–851. （in Chinese）.

[10] Y. A. Li: Multifunctional n-1-order current-mode filter based on AOA's. Electronic components & materials, Vol. 26, No. 11 (2007), p.32–34. （in Chinese）.
