Optimal Design of an Ultrasonic Transducer in Rotary Ultrasonic Machining

Abstract:

In this paper, an ultrasonic transducer is designed and optimized in order to reduce the error of resonance frequency and maximize the amplitude of the radiating tip. In order to get the basic dimensions of an ultrasonic transducer easily, resonance frequency equations are derived by using the traditional analytic method. Using ANSYS FEM software, we analyzed the vibration model of the transducer, including Modal Analysis and Harmonic Response Analysis. Studied how the length of two resonance rods affects the resonance frequency. By optimizing the dimensions of the ultrasonic transducer, the error of resonance frequency is reduced to 0.03%; the amplitude of the vibrating tip is up to 6.20μm. The optimal results show that the transducer designed in this paper has superior performance parameters and meets the requirements of machining.

You might also be interested in these eBooks

Frontiers of Mechanical Engineering and Materials Engineering

View Preview

Info:

Periodical:

Applied Mechanics and Materials (Volumes 184-185)

Pages:

352-355

DOI:

https://doi.org/10.4028/www.scientific.net/AMM.184-185.352

Citation:

Cite this paper

Online since:

June 2012

Authors:

Fan Chong Zeng, Xiang Hui Zhang

Keywords:

Finite Element Analysis (FEA), Optimal Design, Rotary Ultrasonic Machining, Ultrasonic Transducer

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] C.Y. Khoo, Esah Hamzah and Izman Sudin, A review on the Rotary Ultrasonic Machining of Advanced Ceramics, Jurnal Mekanikal, 25(2008) 9-23.

Google Scholar

[2] Martine Wevers, Lafaut Jean Pierre, Luc Baert, Low-frequency ultrasonic piezo ceramic sandwich transducer, Sensors and Actuators A: Physical, 122(2005): 284-289.

DOI: 10.1016/j.sna.2005.05.009

Google Scholar

[3] Yan Zhongyu, Lin Zhongmao, Optimum design for sandwich transducer-by analyzing effects of structure and material parameters of transducer on its performance, Acta Acustica, 20(1995): 18-25.

Google Scholar

[4] Jia Yang, Shen Jianzhong, Finite element analysis of stepped ultrasonic horn with different transitional sections, Technical Acoustics, 25(2006): 75-81.

Google Scholar

[5] H. H. Hansen, Optimal design of an ultrasonic transducer, Structural and Multidisciplinary Optimization, 14(1997) 150-157.

Google Scholar

[6] Information on http: /www. kxcad. net/ansys/ANSYS/workbench/ds_harmonic_analysis_type. html.

Google Scholar
