Analysis of Tubing Collapse Failure during the Operation of Blending Light Dropping Viscosity

Abstract:

The heavy oil is the key point which China develops, at present the heavy oil is produced using the technique of blending light dropping viscosity, in addition to usual tubing failure ( pull out, fracture, perforation, corrosion etc.), a new failure form appeared that is tubing collapse, especially in western oilfields China. For the tubing collapse failure in heavy oil recovery well, this paper used the method which the experiment and the theory unify to launch on the analysis research, and mainly considered and analyzed tubing collapse strength under two kind of operating condition according to the field operation situation. This paper pointed out that should consider the bending effect in the pipe string design and the field operation, and must carry on the preliminary calculation to the anti-extrusion pressure in front of the field operation, in order to control the biggest anti-extrusion pressure in the annulus.

• Periodical: Applied Mechanics and Materials (Volumes 184-185)
• Pages: 719-723
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.184-185.719
• Online since: June 2012
• Authors: Jian Jun Wang, Yao Rong Feng, Zhi Yong Luan, Gang Wang
• Keywords: Blending Thin Oil, Collapse, Heavy Oil Recovery, Tubing

References

[1] MA Xin-fang, ZHANG Shi-cheng, YANG Sheng-lai1. Study of experiment and numerical simulation of superheavy oil production by mixing light oil. J. Journal of China University of Petroleum, 2006, 30(4) 63-66.

[2] Jiang Yong. Application of Blending Light Dropping Viscosity Testing Technology for Heavy Oil Well in Tahe Oilfield. J. Well Testing, 2004(4) 73-74.

[3] Liu Jian-hua, Xu Fu-dong. Relationship between Pump Pressure and Admixture Ratio in Viscous Oil production of Tuha Oilfield. J. Journal of Oil and Gas Technolog, 2005, 27(6) 968-969.

[4] Lin Riyi, Li Zhaomin, Wang Jingrui. Technology of blending diluting oil in ultra-deep wellbore of Tahe Oilfield. J. Acta Petrolei Sinica, 2006, 27(3) 115-119.

[5] API RP 5C5, Recommended Practice on Procedures for Testing Casing and Tubing Connections. third edition, 2003. Washington DC: API, p.71.

[6] API Bull 5C2, Bulletin on Performance Properties of Casing, Tubing, and Drill Pipe. twenty-first edition, 1999. Washington DC: API, p.2.

[7] ISO/TR10400, Petroleum and natural gas industries — Equations and calculations for the properties of casing, tubing, drill pipe and line pipe used as casing or tubing. first edition, 2007. Geneva, Switzerland: International Organization for Standardization.

DOI: 10.3403/30175233u

[8] China Petroleum Tubular Goods Standardization Committee. SY/T 5724—2008 Design of casing string structure and strength. Beijing: Petroleum Industry Press, 2008, p.12.
