Study on the Trajectory Planning of Hybrid-Driven Planar 3-RRR Mechanism

Abstract:

Hybrid-driven mechanism synthesis the constant speed motor and the servo motor as the power source through a multi degree of freedom mechanism. The text study on the trajectory planning of hybrid-driven planar 3-RRR mechanism. Firstly, based on compatible link combinations, all possible basic configurations of planar 3-dof kinematics chains were derived. Based on the requirements of hybrid-driven mode, the kinematics chains were selected one by one Planar 3-RRR mechanism was determined to be the research object finally. Then, based on the conclusions of inverse kinematics analysis, using the cubic spline function on point to point path planning, the servo motor rotation laws were presented. Comparing the different speed situation of constant motor, the influence trends on planning results were analyzed.

• Periodical: Applied Mechanics and Materials (Volumes 190-191)
• Pages: 733-738
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.190-191.733
• Online since: July 2012
• Authors: Sheng Tao Song, Rui Qin Li, Ai Ling Wang, Yan Gao
• Keywords: 3-DOF, Hybrid-Driven Mechanism, Planar 3-RRR Mechanism, Trajectory Planning

References

[1] Tokuz L C, Jones J R. Programmable modulation of motion using hybrid machines. [J]Proceedings of IMECHE. 1991:85-91.

[2] Tokuz L C. Hybrid machine modeling and control. [J]UK: Liverpool Polytechnic. 1992:356-360.

[3] Greenough J D. Design of hybrid machine. [J]Proceeding of the 9th IFToMM World Congress. 1995:2501-2505.

[4] Herman J, Van de Straete, Joris de Schutter. Hybrid cam mechanism. [J]ASME Transactions on Mechatronics. 1996, 1(4):284-289.

DOI: 10.1109/3516.544789

[5] Rockwell Automation. Press Release(www.ab.com./events/presser1/9706/97061d.html).

[6] Zhou Shuanglin. Design Theory and experimental study of the five bar of the hybrid driven to achieve trajectory. [D] Shanghai: Shanghai Jiaotong University, 2001.

[7] Shan Ning. Study on the analysis and experimental of the hybrid driven Linkage.[D]Xi'an:Xi'an University of Technology,2005.

[8] Fang Xinguo. Study on the hybrid driven design theory and experimental of planar two DOF seven bar. .[D]Shanghai: Shanghai Jiaotong University, 2003.

[9] Li R Q,Dai J S.Crank conditions and rotatability of 3-RRR planar parallel mechanisms. [J]Sci China Ser E-Tech Sci.2009,52.12:3601-3612

DOI: 10.1007/s11431-009-0290-2

[10] Gosselin C M, Angeles J. The optimum kinematic design of a planar three degree of freedom parallel manipulator. [J]ASME Journal of Mechanisms, Transmissions, and Automations in Design. 1988,110(1):35-41.

DOI: 10.1115/1.3258901

[11] Gosselin C M. Singularity analysis of closed-loop kinematic chains. [J] IEEEE Trans On Robotics and Automation. 1990, 6(3):281-290.

DOI: 10.1109/70.56660

[12] Guo Xijuan, Zhu Sijun, Huang Zhen. Analysis of planar 3RRR parallel mechanisms kinematic.[J] Robot Technique and Application,2002.4:41-45.
