Research on the EM Modeling of Optimization of PCB Grounded Via

Abstract:

Grounded vias modeling is used to analyze the impact on the high speed PCB EMC and SI issues in three aspects, including theoretical analysis, simulator modeling and practical PCB test. In this paper, we discuss the full-wave complex scattering parameter model and full-wave model. Then the full-wave analysis model of the through holes for model validation and comparison are established, by using numerical simulation software HFSS and CST Microwave Studio. The initial test results on the practical PCB show that the analyzed method is reasonable and accurate. And optimized design parameters can ensure the continuity of the impedance of vias, and introduce lesser return loss and insertion loss. It is shown that the signal transmission performance is greatly improved with the grounded via added, which is helpful in specifying the manufacturing tolerance of via designs.

• Periodical: Applied Mechanics and Materials (Volumes 195-196)
• Pages: 1153-1157
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.195-196.1153
• Online since: August 2012
• Authors: Liang Qi Gui, Cao Yang, Jia He, Xiao Ping Gao, Ke Chen, Wei Guo, Qing Xia Li
• Keywords: Co-Simulation, Grounded via Model, PCB Design, Signal Integrity, Structure Parameter

References

[1] C. Schuster, Y. Kwark, G. Selli, et al. Developing a physical model for vias, DesignCon 2006, Santa Clara, CA. pp.58-59, February, (2006).

[2] Laermans E, J. D. Geest, D. D. Zutter, et al. Modeling differential via holes[J]. IEEE Trans. Advanced Packaging, 2001, 24(3): pp.357-363.

DOI: 10.1109/6040.938303

[3] HOU Ying-ying, GUAN Dan-dan. Research on Via Design in High-speed PCB, ELECTRONICS&PACKAGING, 2009(8): pp.20-23. (in chinese).

[4] Eric Bogatin. Signal Integrity: Simplified. Beijing: Electronic Industry Press, 2004. pp.357-363.

[5] ZHANG Ge-zi, JIN Li-hua. Simulation and analysis of high-speed differential via. Information Technology. 2007(5): pp.99-101. (in chinese).

[6] Ansoft Corporation, HFSS Full Book[R]. Ansoft Corporation, (2005).

[7] ZHANG Min, Microwave Studio Full book[R]. Chengdu: University of Electronic Science and Technology University Press, 2010. (in chinese).
