Finite Element Analysis (FEA) for Prediction of Wrinkling in Aluminum 6061-T6 Sheets

Abstract:

Aluminum is one of the most popular metal in a wide variety of applications in manufacturing of components for airplanes, automobiles, house hold etc. A wide variety of parts are manufactured using aluminum sheet of different alloy composition. Wrinkling of sheet metal is the most undesirable phenomenon in sheet metal forming, drawing, punching and other similar manufacturing processes. Current research is focused on Finite Element Analysis of Aluminum 6061-T6 sheet to simulate onset and growth of wrinkles of various thicknesses using ANSYS. Based on the results a comparison was drawn between the wrinkling behaviors at varying load values.

• Periodical: Applied Mechanics and Materials (Volume 197)
• Pages: 691-695
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.197.691
• Online since: September 2012
• Authors: Irfan Manarvi, Amer Sattar, Jawad Ahmed Jadoon
• Keywords: Aluminum Sheet, Finite Element Analysis (FEA), Wrinkling, Yoshida Specimen

References

[1] Xi Wang, Jian Cao, prediction of side-wall wrinkling in sheet metal forming processes , International Journal of Mechanical Sciences 42 (2000).

DOI: 10.1016/s0020-7403(99)00078-8

[2] J Hematian and P M Wild Initial imperfections and the initiation of wrinkling in finite element modelling of deep drawing, Proceedings of the Institution of Mechanical Engineers, Part E: Journal of Process Mechanical Engineering( 2000).

DOI: 10.1243/0954408001530227

[3] Hakim S. Sultan Aljibori, Finite Element Analysis of Sheet Metal Forming Process, European Journal of Scientific Research ISSN 1450-216X Vol. 33 No. 1 (2009).

[4] Ronaldo I. Borja, Finite element simulation of strain localization with large deformation: capturing strong discontinuity using a Petrov–Galerkin multi scale formulation, ELSEVIER, Comput. Methods Appl. Engrg. 191 (2002) 2949-2978.

DOI: 10.1016/s0045-7825(02)00218-9

[5] A. Selman et al, Adaptive Numerical Analysis of Wrinkling in Sheet Metal Forming, Netherlands Institute for Metals Research - Rotterdamseweg 137 - 2628 AL Delft - The Netherlands.

[6] Xiafeng Su, Frank Abdi et al, wrinkling analysis of a Kapton square membrane under tensile loading, 44th AIAA/ASME/ASCE/AHS Structures, Structural Dynamics and Material Conference 7-10 April 2003, Norfolk, Virginia.

DOI: 10.2514/6.2003-1985

[7] H. S Cheng, J. Cao et al, Wrinkling behavior of laminated steel sheets, Journal of material processing technology 151 92004) 133-140.
