Design and Analysis of the Dismountable Frame Structure for Vacuum Container

Abstract:

Painting is one of the most important processes in decorating industrial product. But the vacuum container is the key of vacuum painting equipment. This paper analyzes the principle of dismountable vacuum container’s structure and establishes its basic physical model and simulates its environment load by the finite element software, then analyzes the important component and obtains the index of reliability and safety of dismountable vacuum container. According to the classic theory of elastic thin plate, the accuracy of the results of finite element analysis is proved. Then the further optimization design and the further finite element analysis are utilized to optimize the important component of vacuum container, finally the results meet the requirements.

• Periodical: Applied Mechanics and Materials (Volume 200)
• Pages: 27-31
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.200.27
• Online since: October 2012
• Authors: Yun Xiang Huang, Ke Tian Li, Zhe Hao Tan
• Keywords: Dismountable Frame Structure, Finite Element Analysis (FEA), Tempered Glass, Vacuum Container

References

[1] C.P. Ye, K.T. Li, Z.H. Tan: The Third National Intelligent Manufacture Academic Meeting. (2011).

[2] H.G. Liu: Theory of Plate and Shell (Zhejiang university press, China 1987).

[3] X.K. Huang: Glass Curtain Wall Technical Specifications JGJ102-2003.Beijing.(2003).
