Feasibility Study on Forming Hollow Axle with Multi-Wedge Synchrostep by Cross Wedge Rolling

Abstract:

One direction of the cross wedge rolling technology is to realize high-efficiency, precise and near-net-shape forming hollow axle with multi-wedge synchrostep cross wedge rolling. This paper deduced the rotated condition of forming hollow shaft with multi-wedge cross wedge rolling (MCWR) base on forming solid shaft with single-wedge cross wedge rolling, and analyzed technics parameters on the influence of rotated conditions. Through the finite element simulation we got rolling technics parameters on the effect of rolled piece and selecting principle, and then created the 3D model of the equal diameter period of hollow axle with the MCWR. By using DEFORM-3D software, the process of rolling equal diameter period was simulated. The result indicated that it is feasible to roll hollow axle with multi-wedge synchrostep by cross wedge rolling.

• Periodical: Applied Mechanics and Materials (Volumes 201-202)
• Pages: 673-677
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.201-202.673
• Online since: October 2012
• Authors: Bao Sou Sun, Xue Lei Zeng, Xue Dao Shu, Wen Fei Peng, Pei Sun
• Keywords: Cross Wedge Rolling (CWR), Hollow Axle, Multi-Wedge Synchrostep, Process Parameter

References

[1] X.D. Shu: Theory and Application of Mutil-wedge Synchrostep Rolling by Cross Wedge Rolling (Science Press, China, 2011).

[2] X.D. Shu, C.M. Li and Z.H. Hu: Journal of University of Science and Technology Beijing, Vol. 29, (2007) No.2, pp.159-161.

[3] C.M. Li, X.D. Shu and Z.H. Hu: China Mechanical Engineering, Vol. 17, (2006) No.19, pp.2017-2019.

[4] A.Showky,T.Rosenberger and M.Elbestawi: Mechatronics, Vol. 26, (1998) No.8, pp.301-322.

[5] D.Y. Jang and J.H. Liou: Journal of Materials Proceccing Technology, Vol. 6, (1998) No.74, pp.74-82.

[6] J.C. Liang, G.S. Ren and Z.B. Bai: Transactions of the Chinese Society of Agricultural Machinery, Vol. 26 (1995) No.1,pp.97-101.

[7] Z.H. Hu, K.S. Zhang, B.Y. Wang, X.D. Shu and L.P. Yang: Technology and Simulation of Cross Wedge Rolling Forming Parts (Publishing House of Metallurgical Industry, China, 2004).

[8] W. Ding, K.S. Zhang, L.P. Yang and Z.H. Hu: Jounal of Plasticity Engineering, Vol. 17 (2010) No.3, pp.27-31.
