The Effects of Phase Retardation of Wave Plate on Cesium Magnetometer Sensitivity

Abstract:

The paper described a new magnetometer with cesium vapor in the spin-exchange-relaxation-free (SERF) regime. The variation behavior of phase retardation of the /4 wave plate (in the probing beam direction of this magnetometer) with temperature was introduced, which directly affected the sensitivity of the magnetometer. A detail theoretical analysis was expressed to give the temperature properties of a quartz wave plate. The retardation reduced 0.84 when the temperature increased 1°C for the wave plate with thickness of 2.24 mm and wavelength of 852 nm. According to the various phase retardations of wave plate in different temperatures, the relative intensity of the detection signal in this magnetometer was proposed.

• Periodical: Applied Mechanics and Materials (Volume 203)
• Pages: 263-267
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.203.263
• Online since: October 2012
• Authors: Qing Meng Li, Jun Hai Zhang, Li Li, Xian Jin Zeng, Wei Min Sun
• Keywords: Magnetometer, Phase Retardation, Temperature, Wave Plate

References

[1] H. Acuna: Rev. Sci. Instrum Vol. 73 (2002), p.3717.

[2] D. Budker and M.V. Romalis: Nature Physics 3 (4) (2007), p.227.

[3] H.B. Dang, A.C. Maloof and M.V. Romalis: Appl. Phys. Lett. 97, 51110 (2010).

[4] M.P. Ledbetter, I.M. Savukov, V.M. Acosta, et al.: Phys. Rev. A. 77, 033408 (2008).

[5] P.D.D. Schwindt, B. Lindseth and S. Knappe, et al.: Appl. Phys. Lett. 90, 081102 (2007).

[6] X. Shoujun, V.Y. Valeriy, H.D. Marcus, et al.: Proc Natl Acad Sci USA, 103 (2006), p.12668.

[7] M.P. Ledbetter, I.M. Savukov, D. Budker, et al.: Proc Natl Acad Sci USA, 105 (2008), p.2286.

[8] Qiang Huang, Zongjun Huang, Qiang Liu, Junhai Zhang and Weimin Sun: IEEE. MIC2012 (in press).

DOI: 10.1109/mic.2012.6273303

[9] Stewart R. M. Robertson: Appl. Opt. 22(14) (1983), p.2213.

[10] Junhai Zhang, Qiang Liu, Xianjin Zeng, Jiuxing Li and Weimin Sun: Chin. Phys. Lett. vol. 29, No. 6, 068501 (2012) (in press).

[11] M.P. Kothiyal and C. Delisle: Opt. Lett. 9 (8) (1984), p.319.

[12] Lianke Song, Guohua Li, Zuoxiao Dai, et al.: J. Optoelectronics ×Laser, 8(6) (1997), p.454.

[13] Jingzhen Li: Shanxi Science and Technique Press, 1185 (2010) (in Chinese).
