Research on Welded Structure Design Technology

Abstract:

In recent years, the feature technology has been widely used in CAD/CAPP/CMA design. This essay comprehensively analyzes and studies on the feature definition, description and expression, according to the characteristics of the welded structure design. Welded structure products feature models applicable to the pressure vessels are developed and designed against the product structure features of, welding types of and connector design requirements for the typical welding structure pressure vessels and by combination of the feature technologies. The feature design of the welded structure is studied by the analyzing the welded structures of the pressure vessels. By study on the welded structure design technologies based on features, parametric design technologies can be applied in the development of the welded structure products to effectively shorten the product development circle, improve the product development quality and increase the levels of information technology applied by a firm.

• Periodical: Applied Mechanics and Materials (Volume 203)
• Pages: 299-303
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.203.299
• Online since: October 2012
• Authors: Dian Can Li
• Keywords: Model, Structure Design, Welding

References

[1] Zhang Xiuzhi, Wei Yanhong, Chen Yuchuan. Welded Process Procedure Design Expert System. Welding, 2003 (2): 2~5.

[2] Li Wushen, Zhou Nianguo. CO2 Gas Protection Welded Process Parameter Expert System. Welding Society and Chian Welding Society. Colloquium of Exchange of Academic and Technical the Computer Applications in the Welding. Taiyuan, 2009. 83~87.

[3] Peng Jinyu, Chen Bingsen, Li Li. Arc Welding Process Formulation and Advisory Expert System Design. China Welding Society of Machinery Engineering Society. (2008).

[4] Zou Jianying, Zhang Fuju, Luo Chuanhong. Flux-cored Arc Welding Process Expert System. Process and New Techniques, 2009, 30 (5): 22~24.

[5] Zhao Yiping, Zhang Honggang, Liujie, et al. Study on Steel Pressure Vessel Welding Process Assessment Expert System. Electric Welding Machine, 2009, 29(9): 13~16.

[6] Yao Zongxiang. Research and Development of Computer-aided Welding Process System of Designing Low-temperature Pressure Vessel. Chongqing: Chongqing University, 2005, 4.

[7] Li Shuai. Design and Realization of Chemical Vessel WCAPP System Nanjing: Nanjing University of Technology, 2005, 6.

[8] Zhu Zhiming. Research and Development of Welding Structural Parts Assembly and Welding CAPP System. Welding Journal, 2007(8).
