Computer Simulation of Forming Technology of Thin Aluminum Engine Cylinder Liners Based on LS-DYNA

Abstract:

The high-silicon aluminum alloy by spray deposition forming is well suited for the engine cylinder liner because of the need of high strength and abrasion resistance, but its forming process is much complex, and many process parameters are involved. In order to lower the investments of time, labor power and money due to the traditional processing methods that need to adjust the craft parameters frequently, the thermal extrusion process and the spinning process that are the most important forming processes in aluminum alloy cylinder liner forming are simulated by the finite element simulation technology. It is found that during the extrusion process, the equivalent stresses near the die are larger, and uneven, the stress gradient is very large, but the maximum stress does not exceed the allowable stress of the material through the numerical simulation; In the spinning process, the stress and deformation are larger at the beginning of the process, but they will have a slight decreasing with the spinning process going on. Throughout the spinning process, the equivalent stress and strain distribution of the spinning component maintained a relatively balanced state basically, which is consistent with the later experimental results. It proves the reliability of the the simulation.

• Periodical: Applied Mechanics and Materials (Volume 203)
• Pages: 290-294
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.203.290
• Online since: October 2012
• Authors: Han Wu Liu, Hong De Ren, Han Xun Lv
• Keywords: Cylinder Liner, Equivalent Stress, Extrusion, LS-DYNA Software, Spinning

References

[1] Zhao H.O. LS-DYNA Dynamic Analysis Guide. Beijing: Weapon Industry Press, (2003).

[2] LiuY, Xin X. R, Liu T. The guide tube extrusion process and die design. Mold industry, 2006, (4): 79-52. (In China).

[3] Wu S. J, Mo J. H. LS-DYNA software-based single point incremental forming process simulation method. Mold manufacturing, 2003, (10): 6-7. (In China).

[4] Ren F C, Zhao G. Q, Wang G.C. The piston head extrusion process of mold design and numerical simulation and optimization. Forging Technology, 2006, 31 (4): 49-52. (In China).

[5] Yue L. Y, Xu L.P. Numerical Simulation of Sheet Metal Stamping . Die & Mold Industry, 2004, (11): 34-37. (In China).

[6] Wang T. Motorcycle cup warm extrusion process and die design research and practice. Beijing: Beijing Jiaotong University, 2006. (In China).

[7] Bai J.Z. LS-DYNA 3D theoretical basis and instance analysis. Beijing: Science Press, (2005).

[8] Shang X. J, Su J.Y. ANSYS/LS-DYNA dynamic analysis methods and practice applications. Beijing: China Water Power Press, (2006).

[9] Li Y. C, Shi D. Y, Zhao Y. ANSYS10. 0/LS-DYNA basic theory and engineering practices. Beijing: China Water Power Press, (2006).

[10] Shi D. Y, Li Y. C, Zhang S.M. Based on the ANSYS/LS-DYNA 8. 1 for explicit dynamic analysis. Beijing: Tsinghua University Press, (2005).
