The Predigest Project of Vehicle-Bone Multimedia Transmission and Control Network Based on FPGA

Abstract:

The design uses 32 ARM processor S3C44B0X and Spartan™ -3E500 FPGA chip produced by Xinlinx company for setting up the hardware platform, and integrates the camera, GPS module, MiniGUI interface module. And realized bus vehicle mounted multimedia transmission control network control based on MOST. All of these are in the purpose of achieving a Predigest Project of vehicle-bone multimedia transmission and control network based on FPGA. The experiment indicated that, the transmission and control network system constructed by S3C44B0X and Spartan - 3E500 FPGA is low cast, simple and reliable.

• Periodical: Applied Mechanics and Materials (Volume 203)
• Pages: 62-66
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.203.62
• Online since: October 2012
• Authors: Hong Li, Qiao Zhen Hou
• Keywords: Field-Programmable Gate Array (FPGA), MOST Bus, S3C44B0X, Spartan™-3E500, Vehicle-Bone Multimedia

References

[1] Qin Guihe. Vehicle network technology [M]. Beijing: Machinery Industry Press, 2003: l44-l45.

[2] Oasis Silicon Systems AG．0S8104 MOST Network TransceiverDataSheet[Z]．Austin．USA：Oasis Silicon Systems AG. 2003: 20—21.

[3] Cirrus Logic CS8413/14 Product Data Sheet DS240F1[Z]．Austin，USA：Cirrus Logic．(1998).

[4] MOST Cooperation. Most Specification Framework Rev1. 1[Z]. Karlsruhe, Germany: Most Cooperation, 2001: 13.

[5] He Limin. I℃bus application system design[M]. Beihang University press 2005: 77-7.
