Finite Element Analysis Simulation of the South-to-North Water Diversion Bridge during Cantilever Construction

Abstract:

Use the Finite Element Analysis software to numerically simulate the South-to-North Water Diversion Bridge, a prestressed concrete composite box-girder bridge with corrugated steel webs, during the process of cantilever construction. Then research the force condition of the main girder structure during the construction processes. Results indicated that, during each construction process, the bending moment was reasonable, and all sections of the main girder structure were under pressure. The maximum normal stress always appeared around those cross-sections over the main piers, and during the mid-span closure process, the maximum stress appeared around the mid-span segment’s bottom flange.

• Periodical: Applied Mechanics and Materials (Volumes 204-208)
• Pages: 2114-2118
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.204-208.2114
• Online since: October 2012
• Authors: Hua Ma
• Keywords: Cantilever Construction, Corrugated Steel Web, FEA Simulation, Normal Stress

References

[1] Rosignoli M. Proceedings of the Institution of Civil Engineers, Structures and Buildings, 1999, 134(1): 77-85.

[2] Sayed-Ahmed E Y. Can J Civ Eng, 2001, 28(4): 656-672.

[3] B.C. Chen and Q.W. Huang. Journal of Highway, 2005, 50(7): 45-53. (In Chinese).

[4] B.C. Chen, Y.Y. Chen and S. Lin. Journal of China and Foreign Highway, 2010, 30(1),: 109-118. (In Chinese).

[5] L.C. Fan. Bridge Engineering [M]. Beijing: China Communications Press, 2001. (In Chinese).

[6] J.Y. Zhang and C.J. Wang. Cantilever Pouring of Continuous Prestressed Concrete Girder Bridge [M]. Beijing: China Communications Press, 2004. (In Chinese).

[7] J.Y. Gong. Sichuan Architecture, (2007).

[8] P. R. China. Ministry of Communications. General Code for Design of Highway Bridges and Culverts (JTG D60-2004). Beijing: China Communications Press, 2004. (In Chinese).
