Tests before and after Reinforcement of Tujiazui Bridge

Abstract:

This paper is aimed to verify the effects of reinforcement by tests before and after reinforcement of a two-way curved arch bridge with a clear span of 70m. Four 100kN and 180kN trucks are used for load tests of the bridge before and after reinforcement, and then the test values are compared with the calculated values. Tests before reinforcement has proved insufficient rigidity in some parts of the bridge, the design load grade is low, and the common fault in two-way curved arch bridges. The finite element numerical analysis tool ANSYS is used for finite element simulative analysis of the bridge, and the comparison of test values with calculated values shows the bridge can meet the existing design load grade after reinforcement. This paper has verified the feasibility and rationality of utilizing the physical unit of ANSYS for analysis of two-way curved arch bridges after reinforcement, and meanwhile, proved that the rigidity and design grade of bridges can be improved by reinforcement.

• Periodical: Applied Mechanics and Materials (Volumes 204-208)
• Pages: 2095-2099
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.204-208.2095
• Online since: October 2012
• Authors: Xu Yong Chen
• Keywords: Finite Element, Reinforcement, Test, Two-Way Curved Arch Bridge

References

[1] Chen xuyong, Fanjianping, Wangguoding. Investigation of Special-shaped Section Arch strengthening technique on Double Curved arch bridge and Optimization Design, Journal of Wuhan University of Technology, 2009, 31 (5) : 70-74.

[2] Chenxuyong. The investigation on reliability evaluation and new techniques in strengthening and rebuilding of double curved bridges. Master's degree thesis of Huazhong University of science and technology. (2007).

[3] The consultation and supervision centre of highway engineering of Hubei province. The load test Report of Tujiazui bridge in Ezhou. (2002).

[4] The consultation and supervision centre of highway engineering of Hubei province. The load test Report of Tujiazui bridge in Ezhou. (2004).

[5] China Academic of Transportation Sciences, Highway double curved arch bridge ( Design and calculating of superstructure. Beijing: China Communication Press, (1983).

[6] Wang minqiang, Wangle, Zhanghuan, Hanqifeng. Finite element analysis and test study for a hollow double curvature arch bridge. Engineering Journal of Wuhan University. 2005, 38 (5): 88-93.

[7] Wang zhenling. Investigation of the theory and experiment of bond between new and old concretes applying in bridge strengthening engineering. Doctor's degree thesis of Southeast Jiaotong University. (2007).
