Design Study of Dual Generated Radial Flux Permanent Magnet Generator for Pico Hydro Generator

Abstract:

The RFPM(Radial Flux Permanent Magnet) generator has numerous advantages such as high output voltage and output power, high efficiency, manufacture easy but the slotted RFPM generator configuration produces the cogging torque. The cogging torque would be the source of acoustic noise and vibration. This paper presents the electromagnetic structure design analysis and the cogging torque reduction design of RFPM generator. It is composed of the inner stator and the outer stator and internal rotor. We called it as DG-RFPMG(Dual Generator-Radial Flux Permanent Magnet Generator). Firstly, the design of the pole-arc ratio of rotor magnets to reduce cogging torque is studied. Secondly, the design of the stator displacement of the outer stator and the inner stator to reduce the cogging torque is studied. Finally, the combined design optimization considering both the pole- arc ratio and the stator displacement to reduce the cogging torque is studied. The design of DG-RFPMG was calculated by 2D FEM(Finite Element Method).

• Periodical: Applied Mechanics and Materials (Volumes 212-213)
• Pages: 1025-1029
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.212-213.1025
• Online since: October 2012
• Authors: Gyeong Chan Lee, Hoe Cheon Kim, Tae Uk Jung, Jang Mok Kim
• Keywords: Cogging Torque, Dual Stator, RFPM

References

[1] Dj Kamaruzzaman Sopian, and Juhari Ab. Razak, "Pico Hydro : Clean Power From Small Streams," Proceedings of the 3RD WSEAS International Conference On Energy Planning, Saving, Environmental Education, EPESE '09, Renewable Energy Sources, RES '09, p.414–419, 2009.

[2] H. Zainuddin, M. S. Yahaya, J. M. Lazi, M. F. M. Basar and Z. Ibrahim, "Design and Development of Pico-hydro Generation System For Energy Storage Using Consuming Water Distributed to Houses," Proceedings of Worls Academy of Science, Engineering and Technology 59, p.pp.154-159, November 2009.

DOI: 10.1109/icdret.2009.5454216

[3] Y. Mishing, in: Diffusion Processes in Advanced Technological Materials, edited by D. Gupta Noyes Publications/William Andrew Publising, Norwich, NY (2004), in press.

[4] J.R. Bumby, R. Martin, "Axial-flux permanent-magnet air-cored generator for small-scale wind turbines", in Proceedings of IEEE Electric Power Applications, vol. ps-152, no.5. pp.1350-2352, Sep. (2005)

DOI: 10.1049/ip-epa:20050094

[5] Kartik Sitapati, R Krishnan, "Performance Comparisons of Radial and Axial Field, Permanent-Magnet, Brushless Machines", in Proceedings of Ieee Industry Applications, vol.37, no.5. pp.1219-1226, Sep.2001.

DOI: 10.1109/28.952495

[6] P. M, Zhu. Z. Q, Lipo. T. A, Howe. D,"Minimization of Cogging Torque in Axial Flux Permanent Magnet Machines Design Concepts", IEEE Transactions on Magnetics, vol. PS-43, no.9. pp.3614-3622, Sep. 2007.

DOI: 10.1109/tmag.2007.902818

[7] Alvaro B. Letelier, Delvis A. Gonzalez, Juan A. Tapia, "Cogging Torque reduction in an axial flux pm machine via stator slot displacement and skewing", IEEE TRANSACTIONS ON INDUSTRY APPLICATIONS, VOL. 43, NO. 3, MAY/JUNE (2007)

DOI: 10.1109/tia.2007.895738
