Numerical Investigation of Impact of Pile Space on Flow around Two Vertical Cylindrical Piles

Abstract:

The flow around two vertical cylindrical piles exposed to a steady current is studied numerically by a three-dimensional hydrodynamic model, which is closured with a k-ε turbulence model. This model is firstly validated by experimental data obtained from a labortory experiment for a steady flow through a circular pile. Then this validated model is used to study flow pattern around two cylindrical piles. Finally, four key physical factors of the size of the horseshoe vortex and lee wake vortex, the maximum current velocity and bottom shear stress are analyzed under the different pile spaces. The main conclusions are: i) the size of the horseshoe vortex increases with the increase of the two pile space, while the size of the lee wake vortex changes slightly; ii) the maximum current velocity and the maximum bottom shear stress decrease with the increase of two pile space, and reach steady after the two pile space larger than six times of cylindrical pile diameter.

• Periodical: Applied Mechanics and Materials (Volumes 212-213)
• Pages: 1103-1107
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.212-213.1103
• Online since: October 2012
• Authors: Jian Wen Qi, Cui Ping Kuang, Jie Gu, Jing Huang
• Keywords: Horseshoe Vortex, Lee Wake Vortex, Three-Dimensional Flow, Three-Dimensional Hydrodynamic Model, Vertical Cylindrical Pile

References

[1] Roulund A, Sumer B. M, FredsΦe J et al. Numerical and Experimental Investigation of Flow and Scour around a Circular Pile,. Journal of Fluid Mechanics，2005，534：351—401.

DOI: 10.1017/s0022112005004507

[2] Dargahi B. Controlling Mechanism of Local Scouring, Journal of Hydraulic Engineering, ASCE , 1990, 116(10): 1197—1214.

DOI: 10.1061/(asce)0733-9429(1990)116:10(1197)

[3] Ahmed F and Rajaratnam N. Flow around Bridge Piers, Journal of Hydraulic Engineering, ASCE , 1998, 124(3): 288—301.

DOI: 10.1061/(asce)0733-9429(1998)124:3(288)

[4] Ling J. M, Lin X.P. and Zhao H.D. Analysis of Three-Dimensional Flow Field and Local Scour of Riverbed around Cylindrical Pier,. Journal of Tongji University (Natural Science)，2007，35(5)：582-586 . (in Chinese）.

[5] He G.J., Fang H. W and Fu R.S. Three-dimensional numerical analysis on water flow affected by piers,. Journal of Hydrodynamics, 2007, 22(3): 345-351.

[6] Qu L.Q., Zhou Y.R. and Yang J.X. Experimental Study on Local Scour around Bridge Piers by Wave and Current,. Port & Waterway Engineering, 2006, 387(4): 23-27. (in Chinese）.

[7] Launder B. E and Spalding D.B. The Numerical Computation of Turbulent Flows,. Journal of Hydraulic Engineering, ASCE, 1974, 113, 615-629.

[8] Rodi W. Turbulence Models and Their Applications in Hydraulics, IAHR, Delft, the Netherlands. (1980).
