Describing NC Smooth Path Based on the Adjustable Form of the Cubic Spline Interpolation Function

Abstract:

In order to describe the NC processing path better, and easy to realize path in a smooth transition of inflection point, this paper puts forward a kind of adjustable form of the cubic spline interpolation function; using the function can describe line, arc and freecurve, and realize smooth transition of inflection point through the control points which near the inflexion point. The spline function is of cubic polynomial, which calculation is simple, and it is easy to realize the operation of fast interpolation; it not only can describe various of NC paths, but also can be easy to realize the high speed of smooth processing between the NC orbit segments, which meets the needs of modern numerical control system for high speed, stability and flexible.

• Periodical: Applied Mechanics and Materials (Volumes 215-216)
• Pages: 1158-1164
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.215-216.1158
• Online since: November 2012
• Authors: Ai Ping Song, Jian Huang, Jian Ming Tao, Dan Ping Yi
• Keywords: High Speed Processing, NC Processing, Smooth Path, Spline Function
