A Study on Stoma Arrangement of Air-Cushion Lamination and Numerical Simulation of the Pressure Field

Abstract:

Cushion has a wide range of applications in engineering. It is a new attempt to use it in the field of printing and packaging lamination process, to get a numerical simulation study analyzes for the distribution of the formation pressure of the air cushion pressure chamber. On the basis of analysis of the principle of air-cushion laminated device, make it clear for the requirements of the air cushion pressure distribution, pressure distribution from a single stomatal mathematical model, using ANSYS finite element software, numerical simulation of multi-stoma pressure distribution. The results showed that: stomata arranged in the form of cushion thickness, stomatal spacing and stomatal row spacing uniformity of the distribution greater impact on the cushion pressure; small stomatal spacing and stomatal row spacing will help improve the air cushion pressure distribution uniformity; reasonable cushion thickness stomatal spacing and stomatal row spacing, the selected diameter of the pores smaller cushion pressure distribution uniformity.

• Periodical: Applied Mechanics and Materials (Volumes 217-219)
• Pages: 1416-1420
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.217-219.1416
• Online since: November 2012
• Authors: Bo Gao, Xiao Gui Zhang, Ji Fei Cai
• Keywords: Air-Cushion, Lamination, Packaging, Simulation

References

[1] Xiao chaofeng, P.R.A sheet metal press machine, Patent (2001)

[2] chenyouhua, Dongguan Star Haifeng Electronics Co., Ltd, UV light curing lamination device for key assembly, Patent (2001)

[3] Liu yongtian, zhang hao, chen shuntong. Scud Battery Co., Ltd. A battery assembly lamination equipment, Patent (2001)

[4] Meng fanqiu: Lamination technology research based on the sewing machine of the industrial robot control, Jilin University Dissertation.

[5] Uichiro Nishio, Kei Somaya, Shigeka Yoshimoto: Tribology International, Vol.44 (2011) No.12, p.1790

[6] WAN Min-hong: Machinery Design ＆ Manufacture, (2011) No.12, p.14

[7] A.K. Amiruddin, S.M. Sapuan, A.A. Jaafar: Materials & Design, Vol. 29(2008) No.7, p.1453

[8] Krish P.Thiagarajan, Michael T. Morris-Thomas: Ocean Engineering, Vol.33 (2006), p.1143

[9] LIU Ming, NI Xin-yue, SONG Ri-hong: JOURNAL OF JIANGSU POLYTECHNIC UNIVERSITY, Vol. 20(2008) No.1, p.26
