Investigation on Numerical Calculation of Thermal Boundary Resistance between Superconducting Magnets

Abstract:

Aiming at the problem that thermal boundary resistance (TBR) has an effect on heat transportation of superconducting magnet when Superconducting Magnetic Energy Storage (SMES) is cooled directly, from perspective of numerical calculation, truncated cone, circular arc and triangular models are used to simulate the solid to solid contact surface, and finite element method is adopted to carry on numerical simulation calculation for thermal boundary resistance. With comparison and analysis of the calculation results of the three models, knowing that the value calculated with the triangular model when its control angle is 30° is close to the measured value and its relative error is 17%. Meanwhile, the error source is analyzed. This dissertation can be a good reference to the research on superconducting magnet heat transportation.

• Periodical: Applied Mechanics and Materials (Volumes 217-219)
• Pages: 2505-2509
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.217-219.2505
• Online since: November 2012
• Authors: Hu Du*, Gang Wu, Xiang Li, Ke Bi, Ji Ma, Hui Ling Wang
• Keywords: Finite Element Method (FEM), Geometric Model, SMES, TBR

References

[1] Phelen P E. Application of diffuse mismatch theory to the prediction of thermal boundary resistance in thin film high Tc superconductors [J]. Journal of Heat Transfer, 1998, 120(1): 37-43.

DOI: 10.1115/1.2830060

[2] Hu Youming, Paul Luyeye Luymas, Wang Huiling. A method of calibrating the NiCr-CuFe cryogentic thermocouple in laboratory [J]. Gryogenics, 1997, 4(6): 23-26.

[3] Bush A W, Gibson R D. The elastic contact of a rough surfaces[J]. Wear, 1975, 35: 87-111.

[4] Bush A W, Gibson R D, Keogh G P. Strongly anisotropic rough surfaces[J]. Journal of Lubrication Technology Transactions ASME, 1979, 101(1): 15－20.

DOI: 10.1115/1.3453271

[5] Cooper M G, Mikic B B, Yovanovich M M. Thermal contact conductance[J]. Int J Heat Mass Transf, 1969, 12: 279-300.

DOI: 10.1016/0017-9310(69)90011-8

[6] Lambert M A, Fletcher L S. Review of models for thermal contact conductance of metals[J]. J Thermophys Heat Transf, 1997, 11(2): 129-140.

[7] Mikic B B. Thermal contact conductance[J]. Int J Heat Mass Transf, 1974, 17: 205-214.

[8] Shen Jun, Ma Jun, Liu Weiqiang. A Numerical Calculation Method of Thermal Contact Resistance [J]. Aerospace Shanghai. 2002, 4: 33-36.

[9] S.T.Wu. Application guide of surface roughness[M]. Beijing: China machine press, 1990: 218-220.

[10] W.Q. Tao. Modern progress of numerical heat transfer [M]. Beijing: science press, 2000: 71-80.

[11] R.S. Rao, J.R. Wang , H.R. Zhuang, H.L. Wang. Experimental investigation on the thermal interface of Bi-2223-to-AlN contact for HTS cryocooler cooling [J]. Gryogenics. 2002. 5: 12-16.

[12] L.P. Zhao, L.Xu, Theoretical Analysis of Thermal Contact Resistance between Solid Interfaces [J]. Chinese space science and technology.2003(4): 6-11.
