Mechanical Structure Design of Ontology of the Automatic Line-Tracking Inspection Device Based on Pro/E Modeling and the Kinematics Analysis

Abstract:

A new line-tracking inspection device which can move on the high voltage transmission lines and control on the ground by people is presented in this paper. The device has three mechanical arms, every arm can lift and rotate automatically, and manipulator can open and close automatically. The flexible design is used in lower riding wheel, this design can make the upper and lower riding wheel automatically adjustment, so as to adapt to the change of wire diameter. Automatic checking and autonomous negotiating obstacles are realized successfully in this device. The biggest breakthrough is that its automatic on-line or off-line can be completed by operator operating the auxiliary tools on the ground. This article uses the Pro/E modeling software set up the virtual prototype of the line-tracking inspection device based on characteristic parameter model. The process of on-line or off-line automatically and the process of negotiating obstacles are discussed in this paper. Using the product of exponentials formula based the on screw theory, the kinematics analysis is processed in this paper. The forward and inverse solution of kinematics equations is presented and at last the Jacobian matrix is given. The results of experiments with simulation transmission lines demonstrate that the device has realized the specified work tasks and runs smoothly.

• Periodical: Applied Mechanics and Materials (Volumes 220-223)
• Pages: 1131-1137
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.220-223.1131
• Online since: November 2012
• Authors: Sheng Mei Luo, Le Tian, Bo Zhang
• Keywords: Automatic Line-Tracking Inspection Device, Kinematics Analysis, Mechanical Structure, Obstacle Negotiation, On-Line and Off-Line Automatically, Pro/E Modeling

References

[1] Sawada J, Kusumoto K, Maikawa Y, et al. A Mobile Robot for Inspection of Power Transmission Lines .IEEE Trans on Power Delivery, 1991, 6(1):309~315.

DOI: 10.1109/61.103753

[2] Harvard D.G., Bellamy G., Buchan P.G., Ewing H.A., Horrocks D.G., Krishnasamy S.G., Motlis J.,Yoshiki-Gravelsins K.S. Aged ACSR conductors.I. Testing procedures for conductors and line items;Power Delivery,IEEE Transactions on,Volume:7,Issue:2,1992,Pages:581-587.

DOI: 10.1109/61.127052

[3] Shin-ichi Aoshima, Takeshi Tsujimura, .A wire mobile robot with multi-unitstructure[C] In: IEEE/RSJ International Workshop on Intelligent Robots and Systems. Tsukuba, Japan, 1989:414-421.

DOI: 10.1109/iros.1989.637939

[4] Gongping WU, Xiaohui XIAO, et al., "Development of a Crawling Robot for Overhead High Voltage Transmission Line, China Mechanical Engineering, vol. 17, 2006, p.237–240.

[5] Sheng-mei Luo; Le Tian.Development of automatic line-tracking inspection device for high voltage transmission lines based on ground control[C], 2011 IEEE International Conference on Computer Science and Automation Engineering,CSAE 2011. 2011:422-426. EI (Accession number: 20113414258738).

DOI: 10.1109/csae.2011.5952711
