The Application of ANSYS Stress Concentration Analysis Technique to Etch Pit Analysis on Inhaul Cable

Abstract:

Etch pit is a common local etch on inhaul cable. Etch pit on the surface of steel wire can produce pits and lead to the appearance of stress concentration due to geometrical discontinuity in the pits area on steel wire. After studying various stress concentration analysis techniques, it is concluded P-method is the best method suitable for the stress analysis of corrosive pits. The analysis results show that the Von. Mises stress at the bottom centre of pits and stress concentration factor in the pit first decreases and then increases with the depth increase of the pits. In the research on steel wire fatigue life, when paying attention to the maximum stress value, it still needs to consider the etch degree on steel wire section. The calculated data lay a certain foundation for the life study of inhaul cable.

• Periodical: Applied Mechanics and Materials (Volume 224)
• Pages: 295-302
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.224.295
• Online since: November 2012
• Authors: Yi Guo, Hua Bin Wen, Xiao Dong Pu, Chuan Hua Lu
• Keywords: Inhaul Cable, Pit Etch, P-Method, Stress Concentration

References

[1] Peter Kohnke. ANSYS theory reference [M]. Release 5. 7 ANSYS Inc, (1999).

[2] J Hu, L X Xu, C K Yao, L C Zhao. Location Corrosion of alumina borate whisker reinforced AA2024 T6 composite in aqueous 3. 5% NaCl solution. Mater Chen Phys, (2002), 76(3): p: 290~294.

DOI: 10.1016/s0254-0584(01)00543-0

[3] Da-Gen Su. Analysis of stay-cable etch and failure [J]. Material Protection, ( 1997), p: 12.

[4] Eldredge G G. Analysis of etch pit by extreme-value statistical and its application to oil well tubing caliper surveys. Etch 1957. 13. 51.

DOI: 10.5006/0010-9312-13.1.67

[5] Huang Yueping, Xu Ming. Inhaul cable local etch inspection and evaluation analysis [J]. Etch Science and Protection Technology, vol. 03, (2006).
