The Determining Method of Background Light Attenuation Coefficient in Discerning of High Temperature Forgings

Abstract:

The key of high temperature forging size measurement based on using CCD is to extract the forging contour from the complex background. According to different forging field conditions, the paper obtains the necessary and sufficient preconditions for forgings discriminated from the background by analysis on the radiation spectral character of the high temperature forgings, the reflective spectral character of the background light and the spectral response character of the color CCD. The preconditions show that only when the reflection of background light less than the radiation of the high temperature forgings can the forgings be discerned completely. This paper proposes an implementation method for size measurement. The method has the advantages of clear concept and low operation costs. It provides the theoretical basis and available way for the discrimination and size measurement of high temperature forgings based on common and special color CCD.

• Periodical: Applied Mechanics and Materials (Volumes 226-228)
• Pages: 1848-1851
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.226-228.1848
• Online since: November 2012
• Authors: Zhong Hui Yin, Chun Li, Jia Bin Nie
• Keywords: Attenuation Coefficient, CCD, Discern, High Temperature Forging, Spectral Character

References

[1] R.M. Wu: Large Size and High Temperature Forging Binocular Stereo Vision Measurement Method (MS, Dalian University of Technology, China 2008), p.2. (In Chinese)

[2] P.Yu: Study on Key Technology of a New Large Forging Dimension Measurement System (MS, Shanghai Jiao Tong University of Technology, China 2008), P.8-9 (In Chinese)

[3] S.M. Nie: Machinist Metal Forming, (2008) No.11, pp.22-25. (In Chinese)

[4] S.M. Nie: Journal of Plasticity Engineering, Vol. 12 (2005) No.7, pp.85-88. (In Chinese)

[5] S.M. Nie: Journal of Plasticity Engineering, Vol. 13 (2006) No.5, pp.110-113. (In Chinese)

[6] S.Y. Ge and H.Y. Na: Thermal Radiation Properties and Measurement (Science Press, China 1989), pp.15-21. (In Chinese)

[7] X.F. Cheng, J.H. Wu and X.Y. Xu: Natural Science Progress , Vol. 11 (2006) No.3, pp.293-299. (In Chinese)
