Dynamic Testing and Analysis of Inflatable Beams

Abstract:

Dynamic testing of an inflatable beam has been performed to evaluate structural natural frequencies and modal damping ratios. The inflatable beam has a pattern of six composite fiber strips inside thin-film structure that increases its local stiffness that the structure can be self-supporting in the gravity environment when the internal pressure is released. A measurement setup was installed, and the dynamic testing was performed in this self-supporting state. Dynamic characters of the beams were tested with internal pressure or not when the beam had a 2.0kg mass on the top. Moreover, the dynamic characters before rolled up were contrasted to one after. The experimental results indicate that the self-supporting inflatable beams had better bending stiffness, and the curl folding process had an impact on the dynamic characteristics of the inflatable beam. The pressure affection is not obvious on dynamics of the beam.

• Periodical: Applied Mechanics and Materials (Volumes 226-228)
• Pages: 546-552
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.226-228.546
• Online since: November 2012
• Authors: Jian Zheng Wei, Hui Feng Tan, Jian Xin Yu, Xing Wen Du
• Keywords: Beam, Dynamic, Inflatable, Testing

References

[1] R. E. Freeland, G. R. Veal: 7th AIAA/USAF/NASA /ISSMO Multidisciplinary Analysis and Optimization Symposium. (St. Louis MO, USA, 1998). AIAA-98-2104.

DOI: 10.2514/mmao98

[2] P K. Malone, G. T. Wilhrns: Journal of Propulsion and Power, Vol.12 (1996), p.1.

[3] D.T. Griffith, J.A. Main: Proceedings of the 18th International Modal Analysis Conference,(San Antonio, TX, February 2000).

[4] G. Park, E. Ruggiero, and D. J. Inman: Smart Mater. Struct., Vol. 11 (2002), p.147.

[5] K. B. Smalley, M. L. Tinker: Journal of Spacecraft and Rockets, Vol.39 (2002) No.5, pp.732-739

[6] A. Srivastava, B. K. Mishra, and S. C. Jain: Journal of Sound and Vibration, Vol. 309 (2008), p.320.

[7] J. A. Main, R. A. Carlin, E. Garcia, S. W. Peterson, and et al: Journal of the Acoustical Society of America, Vol. 97 (1995) No.2, p.1035.

[8] K. N. Slade, and M. L. Tinker: Proceedings of the 40th Structures, Structural Dynamics, and Materials Conference, (Reston, VA, 1999). p.2495.

[9] K. N. Slade: Dynamic Characterization of Thin Film Inflatable Structures, (Ph.D., Duke Univ., Durham, NC, 2000).

[10] J. Lassiter, R. Fischer, G. Schunk, M. Tinker, and K. Slade: Gossamer Spacecraft: Membrane and Inflatable Structures Technology for Space Applications, (Reston, VA, 2001). Vol. 191 (2001), p.333.

DOI: 10.2514/5.9781600866616.0333.0379

[11] B. Yang, H. Ding, H. Fang, and et al: Proceedings of IDETC/CIE 2005 ASME 2005 International Design Engineering Technical Conferences & Computers and Information in Engineering Conference. (Long Beach, California USA, Sept. 24-28, 2005), DETC2005-84519.

[12] J. Z. Wei, H. F. Tan, H. W. Sun, and X.W. Du: 51st AIAA/ASME/ASCE/AHS/ASC Structures, Structural Dynamics and Materials Conference, (Orlando, FL, April 12-15 2010), AIAA- 2010-2580.

DOI: 10.2514/msdm10

[13] H. Fang, M. Lou, and J. Hah: Journal of spacecraft and rockets, Vol. 43 (2006) No.1, p.25.

[14] S. J. I. Walker, A. McDonald, and T. Niki: Acta Astronautica, Vol. 68 (2011), p.1185.
