Study on Twin-Rotary Motion Control System Based on Siemens Technology CPU

Abstract:

A twin-rotary motion control system was built based on a cam technology and Siemens S7-300T PLC in this paper. The system can position accurately in a three-dimension space using a twin-servo closed loop control system and can real-time monitor various parameters of positioning system by HMI (Human Machine Interface). It also can automatically collect various parameter information and judge the type of fault.At the same time, the degree of automation has been raised and the cost of production was reduced.

• Periodical: Applied Mechanics and Materials (Volumes 229-231)
• Pages: 2201-2204
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.229-231.2201
• Online since: November 2012
• Authors: Cun Hai Pan, Hui Li, Su Mei Du, Wei Gao
• Keywords: Cam Technology, Technology CPU, Twin-Rotary Mechanism, Twin-Servo Closed Loop Control

References

[1] S7-Technology Function Manual. Siemens (2008).

[2] J. M. Krodkiewski: Dynamics of mechanical system. (University of Melbourne Publications, Melbourne 2008).

[3] Cunhai Pan, Ming Chen and Pan Qin: Journal of Tianjin University of Science & Technology Vol. 25 (2010), p.42.
