Aero-Thermal Performance of Purge Flow in Turbine Cascade Endwall Cooling

Abstract:

The endwall and blade film cooling systems are the typical solution adopted within gas turbines to allow further increase of turbine inlet temperature, avoiding critical material thermal stresses. Due to complex secondary flow field in the blade passage, endwallis more difficult to cool than blade surfaces. In the matter of fact, in endwall film cooling studies, it is necessary to investigate the interaction between coolant air and the secondary flow. In present study, the flow field of high-pressure turbine cascade has been investigated by 5-holes pitot tube to reveal the secondary flows behavior under the influenced of purge flows while the heat transfer measurement was conducted bythermochromic liquid crystal (TLC). Experimental has significantly captured theaerodynamics effect of purge flowat blade downstream close to the endwall region. Furthermore, TLC measurement illustrated that the film cooling effectiveness and heat transfer coefficient contours were strongly influenced by the secondary flow on the endwall.

• Periodical: Applied Mechanics and Materials (Volumes 229-231)
• Pages: 737-741
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.229-231.737
• Online since: November 2012
• Authors: W. Ghopa Wan Aizon, Kenichi Funazaki
• Keywords: Endwall Film Cooling, Heat Transfer, Purge Flow, Secondary Flow Field, Upstream Leakage

References

[1] Blair, M.F., 1974, An Experimental Study of Heat Transfer and Film Cooling on Large-Scale TurbineEndwalls, ASME Journal of Heat Transfer, 96, pp.524-529.

DOI: 10.1115/1.3450239

[2] Langston, L. S., Nice, M. L. and Hooper, R. M.; 1977 Three-Dimensional Flow Within a Turbine Cascade Passage, ASME Paper No. 76-GT-50, ASME Journal of Engineering for Power, Vol. 99, pp.21-28.

DOI: 10.1115/1.3446247

[3] Takeishi, K., Matsuura, M., Aoki, S. and Sato, T.; 1990 An Experimental Study of Heat Transfer and Film Cooling on Low Aspect Ratio Turbine Nozzles, ASME Paper No. 89-GT-187, ASME Journal of Turbomachinery, Vol. 112, pp.488-496.

DOI: 10.1115/1.2927684

[4] Wang, H. P., Olson, S. J., Goldstein, R. J. and Eckert, E. R. G.; 1995 Flow Visualisation in a Linear Turbine Cascade of High Performance Turbine Blades, ASME Paper No. 95-GT-7, Texas.

DOI: 10.1115/95-gt-007

[5] Kost, F., and Nicklas, M., 2001. Film-Cooled Turbine Endwall in a Transonic Flow Field: Part I - Aerodynamic Measurements, ASME J Turbomach123, p.709–719.

DOI: 10.1115/1.1400112

[6] Kost, F., and Mullaert, A., 2006. Migration of Film-Coolant from Slot and Hole Ejection at a Turbine Vane Endwall,. GT2006-90355.

DOI: 10.1115/gt2006-90355

[7] Papa, M., Srinivisan, V., Goldstein, R. j., 2010, Film Cooling Effect of Rotor-Stator Purge Flow on Endwall Heat/Mass Transfer, ASME Paper GT2010-23178.

DOI: 10.1115/gt2010-23178

[8] Funazaki, K., 2000, Discussion on Accuracy of Transient Heat Transfer Measurement by Use ofThermochromic Liquid Crystal, Journal of the Gas Turbine Society of Japan, Vol. 28, pp.397-404.
