Robustness Compensation Control of Simulation Loading System Based on Secondary Regulation

Abstract:

This study investigated a mathematical model which was built for a simulation loading system based on secondary regulation. Because the loading system was complicated in structure and some other factors, the control performance was not ideal. Therefore, a dynamic robust compensating controller was designed for the system. The robust compensator could improve the control system by adding the return-to-zero factor and low pass filter on the basis of PID control. This study used MATLAB to simulate the general PID control and the robust compensation control. The results of simulation showed that when the equivalent rotary inertia and damping coefficient changed, the control performance decreased. When using the dynamic robust compensation control, the influences caused by parameter variations were reduced greatly, the system robustness and control accuracy are improved.

• Periodical: Applied Mechanics and Materials (Volume 232)
• Pages: 419-423
• DOI: https://doi.org/10.4028/www.scientific.net/AMM.232.419
• Online since: November 2012
• Authors: Jie Wang, Hui Wang, Zhuo Xu
• Keywords: Robust Compensation, Secondary Regulation, Simulation Loading

References

[1] Jiang Jihai， The study on the hydrostatic transmission system with secondary regulation and its control technique， Ph.D. Thesis， Harbin industrial university. 1998: 2~5.

[2] Kim C S, Lee C O. Load insensitive hydrostatic drive with control of the secondary unit. In: 4th International Conference on Fluid Power, Transmission and Control, Hangzhou China, 1997: 124〜128.

[3] Bi Ningning, Zhang Xianku. Rapid hybird modeling and robust control for hydraulic system. , Applied Science and Technology. 2008, 35(9): 47~49.

[4] Liu Yuhui, Pu Hong, Jiang Jihai. Research on double closed-loop control system of hydrostatic transmission with secondry regulation, Machine tool and Hydraulics. 2001, (1): 39〜40.

[5] Liu Yuhui, Pu Hong, Jiang Jihai. Research on torque control characteristics of hydrostatic transmission with secondry regulation, Machine tool and Hydraulics. 2002, (3): 75〜76.

[6] Li Hongren, Wang Dongliang. Characteristic analyses of the loading system of the vehicle driving bridge with secondary regulation. Machine tool and hydraulics, 2003, 182(2): 111〜113.

[7] Zhan Xingqun, Zhang Yanhua Zhao Keding, Study on Control Characteristics of a Secondary Regulated Loading System, Engineering Science. 2000. 2(7): 47〜54.

[8] Mei Shengwei, Shen Tielong, Liu Kangzhi. Modern robust control theory and application. Beijing: Tsinghua university press, (2003).

[9] Kanellakopoulos I, Kokotovic P, Morse A S. Systematic design of adaptive controllers for feedback linearizable systems . IEEE Trans Automatic Control. 1991, 36( 11) : 1241 -1253.

DOI: 10.1109/9.100933

[10] Wang Hui，Yang Tingting，Wang Chao , Robustness Compensation Control on Servo Loading System Based on Secondary Regulation. Machine tool and Hydraulics. 2009, 37(2): 44~45.

[11] Wang Hui，Yang Tingting， Analysis of robustness control characteristics of servo loading rotational speed system with secondary regulation. Journal of Liaoning Technical University （Natural Science）. 2008. 27(suppl): 241〜242.
